Braze-on Line Piercing Service Valves
Steel pin with core, penetrates
line and is locked into valve
body in one operation, simply by
tightening cap.
Saddle Valves
-
Copper to Copper
Part #
Description
Package
02-CD5514
Saddle for 1/4" line
5/pk
02-CD5516
Saddle for 5/16" line
5/pk
02-CD5538
Saddle for 3/8" line
5/pk
02-CD5512
Saddle for 1/2" line
5/pk
02-CD5558
Saddle for 5/8" line
5/pk
02-CD5534
Saddle for 3/4" line
5/pk
02-CD5578
Saddle for 7/8" line
5/pk
02-CD5518
Saddle for 1 1/8" line
5/pk
Note:
For single pack, use P/N CD1514, etc.
Saddle Valves - Brass to Copper
Part #
Description
Package
02-CD2814
Saddle for 1/4" line
6/pk
02-CD2816
Saddle for 5/16" line
6/pk
02-CD2938
Saddle for 3/8" line
6/pk
02-CD2812
Saddle for 1/2" line
4/pk
02-CD2858
Saddle for 5/8" line
3/pk
02-CD2834
Saddle for 3/4" line
2/pk
02-CD2878
Saddle for 7/8" line
2/pk
02-CD2818
Saddle for 1 1/8" line
2/pk
Saddle Valves - Copper to Copper
Braze-on Service Valves - M Series
Widely used and easily installed on a charged line. Once brazing the
saddle portion onto the line, the steel pin with valve core penetrates the
line and is locked into place by simply tightening the cap.
• Quick, clean access to systems under pressure
• Available from 1/4" to 1 1/8".
• Hardened steel self-piercing needle
• Furnished with cap
Saddle Valves - Brass to Copper
Braze-on Service Valves - Bot Stinger
Simple press saddle into place, apply flux & braze to line. Once cool
screw body with core into saddle, evacuate and charge system.
02-CD5512
Illustrated
02-CD5514
Illustrated
02-CD5516
Illustrated
02-CD5518
Illustrated
02-CD5534
Illustrated
02-CD5558
Illustrated
02-CD5538
Illustrated
02-CD5578
Illustrated
Braze-on Line Piercing Service Valves
Braze-on Line Piercing Service Valves
Special Braze-on Service Valves
V Series
• Copper saddle valve for special use with
02-CD3090 TPA and any CRT.
• Fits nine sizes of copper tubing
• Internally threaded to house a valve core
• Include 02-CD2245 cap
Braze-on Service Valves
Part #
Tubing Size Package
02-CD3036
3/16"
6/pk
02-CD3094
1/4"
6/pk
02-CD3096
5/16"
6/pk
02-CD3098
3/8"
6/pk
02-CD3092
1/2"
4/pk
02-CD3095
5/8"
3/pk
02-CD3034
3/4"
2pk
02-CD3078
7/8"
2/pk
02-CD3018
1 1/8"
2/pk
Designed for use with TPA (Tube
Piercing Attachment) 02-CD3090
• Valve core & cap
included.
• Plated steel body,
CDA 360 brass
saddle.
• Four-way seal
between body and
saddle.
02-CD3097
Illustrated
02-CD3092
Illustrated
02-CD3034
Illustrated
