Refrigeration
Access & Service Valves
Shut-Off Fitting - Quick Couplers
Part #
Description
02-C33112
1/4" quick connect x 1/4" SAE
02-C33113
1/4" quick connect x 90° 1/4" SAE
Replacement o-rings (02-P90022)
02-C33112
Illustrated
02-C33113
Illustrated
02-C33000
Illustrated
Valve core closed.
Refrigerant
trapped in hose.
Positive stop
prevents
rupture
of valve core.
Mini-Manifold Service Valves
Mr. Jr. Charger!
All brass construction. The 1/4" female coupler can be attached to a flare
fitting. Opposite the coupler is the knob for the built-in core depressor. Other
connections are the 1/8" MPT for attaching a gauge and two 1/4"male flares.
One flare fitting has a standard valve core compatible with all refrigerant gases.
Both flare fittings are covered by 02-CD2250 heavy duty brass caps with
neoprene seals and core wrench on top.
Mini-Manifold "Mr. Jr. Charger"
Part #
Description
02-CD1777
Uniquely designed to fit any manufacturers
gauge, and swivel 350° out of the way.
02-CD1777
Illustrated
Refrigerant Control Valves - Back Seating
Part #
Description
02-C33000
1/4" SAE x 1/4" o-ring quick coupler
VAC 1,500 psi (-40°F to 275°F)
Replacement o-rings (02-P90009)
Shut-Off Fitting - Quick Couplers
• Use with existing charging hose.
• Immediately traps refrigerant discharge from
hose when disconnected from access fitting.
• 3/16" and 1/4" coupler with valve core
depressor, safety channels and rubber
gasket seal
• 3/8" couplers with patented O-ring seal for
deep vacuum.
• No depressor.
Refrigerant Control Valves - Back Seating
• Ideal for use on pre-charged line sets.
• Eliminates spraying of leak detection dye and
refrigerant.
• Compact brass body for long service.
• Swivel coupler with double safety grooves.
Access & Service Valve Tap
Access Fittings
