Refrigeration
Refrigeration Application Chart (R12 & R22)*
HP Ref.
Condenser
Type
Normal Evaporating Temperature (°F)
-10 to +5
+5 to +20
+20 to +35
+35 to +50
1/20 R12 Static/ Fan 16"
TC-26
10"
TC-26
1/12 R12 Static/ Fan 12"
TC-26
12"
TC-31
1/9 R12 Static
12"
TC-26
12"
TC-31
1/9 R12 Fan
10"
TC-26
10"
TC-31
1/8 R12 Static/ Fan 10"
TC-26
10"
TC-31
1/6 R12 Static
12"
TC-31
12"
TC-36
1/6 R12 Fan
10"
TC-31
10"
TC-36
8"
TC-36
10"
TC-42
1/5 R12 Static
10"
TC-31
10"
TC-36
1/5 R12 Fan
8"
TC-31
8"
TC-36
71⁄2"
TC-42
71⁄2"
TC-49
1/4 R22 Static/ Fan 12"
TC-36
6"
TC-36
10"
TC-42
6"
TC-42
1/4 R12 Fan
10"
TC-36
6"
TC-36
81⁄2"
TC-42
6"
TC-49
1/3 R22 Fan
10"
TC-36
6"
TC-36
8"
TC-42
6"
TC-49
1/3 R12 Fan
12"
TC-42
13"
TC-36
11"
TC-49
1/2 R22 Fan
6"
TC-36
9"
TC-42
9"
TC-49
6"
TC-54
1/2 R12 Fan
11"
TC-54
9"
TC-49
71⁄2"
TC-54
10"
TC-64
3/4 R22 Fan
11"
TC-54
9"
TC-54
3/4 R12 Fan
71⁄2"
TC-54
12"
TC-70
10"
TC-80
1
R22 Fan
10"
TC-64
12"
TC-70
1
R12 Fan
10"
TC-70
11"
TC-54
71⁄2"
TC-54
(2 pcs)
11⁄2 R22 Fan
71⁄2"
TC-54
(2 pcs)
8"
TC-64
(2 pcs)
11⁄2 R12 Fan
71⁄2"
TC-54
(2 pcs)
9"
TC-64
(2 pcs)
10"
TC-80
(2 pcs)
2
R22 Fan
10"
TC-70
(2 pcs)
9"
TC-75
(2 pcs)
2
R12 Fan
10"
TC-70
(2 pcs)
9"
TC-75
(2 pcs)
10"
TC-85
(2 pcs)
3
R22 Fan
10"
TC-70
(3 pcs)
9"
TC-75
(3 pcs)
3
R12 Fan
10"
TC-70
(3 pcs)
8"
TC-64
(4 pcs)
10"
TC-80
(4 pcs)
4
R22 Fan
10"
TC-70
(4 pcs)
9"
TC-75
(4 pcs)
4
R12 Fan
10"
TC-70
(5 pcs)
9"
TC-75
(5 pcs)
5
R12 Fan
10"
TC-80
(5 pcs)
9"
TC-85
(5 pcs)
* R134a - It is suggested to add 10% to length!
Capillary Tubing
Air-Conditioning Application Chart (R22)*
BTU/
Circuit
Cap Tube
BTU/
Circuit
Cap Tube
Length Size
Length Size
4000 69"
TC-49
8750 78"
TC-75
4250 63"
TC-49
9000 72"
TC-75
4500 90"
TC-54
9250 67"
TC-75
4750 81"
TC-54
9500 84"
TC-80
5000 72"
TC-54
9750 80"
TC-80
5250 63"
TC-54
10000 76"
TC-80
5500 101"
TC-64
10250 72"
TC-80
5750 94"
TC-64
10500 68"
TC-80
6000 87"
TC-64
10750 64"
TC-80
6250 79"
TC-64
11000 90"
TC-80
6500 72"
TC-64
11250 87"
TC-85
6750 64"
TC-64
11500 84"
TC-85
7000 90"
TC-70
11750 78"
TC-85
7250 84"
TC-70
12000 72"
TC-85
7500 78"
TC-70
12500 82"
TC-90
8000 69"
TC-70
13500 66"
TC-90
8250 64"
TC-70
14000 60"
TC-90
8500 84"
TC-75
-
-
-
* R134a - It is suggested to add 10% to length!
Recommended capillary tube lengths for each circuit in an air conditioner
evaporator where R-22 is the refrigerant. All recommendations must
be considered approximate, and variations may arise in actual field
applications.
Window air-conditioners normally have one circuit and the recommended
cap tube can be read directly from the chart. Larger air-conditioners
normally have two or more circuits in the evaporator. Where this is the
case, simply divide the total BTU rating of the unit by the number of cap
tube circuits to obtain the BTU/circuit rating of each individual cap tube.
For BTU amounts not on the chart, use the closest number, i.e. for 7900
BTU, use cap tube for 8000 BTU.
The length and I.D. of any cap tube may be adjusted to a more readily
available size by using the R-Line conversion chart in your R-Line
catalogue and on every box of capillary tubing.
Example
Air conditioner is rated at 27,000 BTU and has 3 cap tubes connected to the evaporator. Divide 27,000 by 3 = 9,000 BTU/Circuit. From the
chart, this would call for .075 I.D. (TC-75) 72" long. The length and I.D. of any cap tube may be adjusted to a more readily available size by
using the conversion chart. Figure after the dash in size listed above designate I.D. of tube (i.e. TC-75 = .075).
Capillary Tubing
