20
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Part # CFM Spd/RPM Volts Amps Rot. Type Const. Bearing
Cross
Fig
R7-RB2
100
1/1550 115 0.47 CW SP
T.E.
Sleeve
Franklin 76002, 80978, Electrohome EB2
1
R7-RB33
100
1/3200 115 0.88 CW SP
Open Sleeve Newmac 204001 EB3 w/ Variable Spd Switch 2
R7-RB54
100
1/3450 115 0.43 CW PSC
T.E.
Ball
Easy Radiant
3
R7-RB120
120
1/3100 115 0.80 CW SP
Open Sleeve
AO Smith 9445
4
R7-RB135
135
1/2600 115 1.30 CCW SP
Open Sleeve
AO Smith 9468, Fasco B24220
5
R7-RB141
140
1/3000 115 1.00 CCW SP
Open Sleeve
AO Smith 9492, Fasco 50752-D500, GRAINGER
4C442
6
R7-RB142
140
1/3000 208/240 0.50 CCW SP
Open Sleeve
AO Smith 9493, Fasco 50752-D230, Grainger
2C915
6
R7-RB140
140
1/2900 115 1.20 CW SP
Open Sleeve
Franklin 76001, 80195
7
R7-RB446
146
1/3120 115 0.75 CW PSC
Open Ball
Grainger 4C446, 1TDP7, Fasco 7021-3469
8
R7-RB155
148
1/2480 115 0.75 CW PSC
T.E.
Ball
Grainger 1TDR6, 4C006, Fasco 7021-4933 9
R7-RB151
150
1/3000 115 1.10 CCW SP
Open Sleeve
AO Smith 9483
10
R7-RB160
160
1/1595 115 1.20 CCW SP
Open Sleeve
AO Smith 458
6
R7-RB180
180
3/1500 115 2.00 CCW SP
Open Sleeve AO Smith 9471, Fasco B47120, Grainger 4C754 11
R7-RB1
200
1/2700 115 1.10 CW SP
Open Sleeve
Franklin 80748, 80981, Electrohome EB1
1
R7-RB245
245
1/1550 115 1.50 CCW SP
Open Sleeve
AMU45, Airdex
12
Fig.1
Fig.3
Fig.2
Direct Drive Blowers
Fig.4
Fig.5
Fig.6
Fig.7
Fig.8
Fig.9
Fig.10
Fig.11
Fig.12
Flange Mounting Dimensions Available on Page 45 & 46
