Butt’s Pumps and Motors - page 1402

19
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Part # CFM Spd/RPM Volts Amps Rot. Type Const. Bearing
Cross
Fig
R7-RB440
50
1/3080 115 0.25 CW PSC
Open Ball
Grainger 1TDN7, 4C440
1
R7-RB55
55
1/1550 115 0.25 CCW SP
Open Sleeve
AO Smith 12
2
R7-RB663
60
1/3000 115 0.60 CCW SP
T.E.
Sleeve
AO Smith 9444
3
R7-RB662
60
1/3000 208/240 0.30 CCW SP
Open Sleeve
AO SMITH 9443, FASCO 50747-D230,
GRAINGER 2C014
4
R7-RB661
60
1/3000 115 0.50 CCW SP
Open Sleeve
AO SMITH 9461, FASCO 50747-D500
4
R7-RB60
60
1/3200 115 0.80 CW SP
Open Sleeve
AO SMITH 9470, FASCO 50747-D401
1
R7-RB665
65
1/3200 115 0.80 CCW SP
Open Sleeve
AO SMITH 9462, FASCO 50748-D500,
GRAINGER 4C443
5
R7-RB70
70
1/3000 115 0.50 CCW SP
Open Sleeve
AO Smith 989
6
R7-RB4
71
1/3220 115 0.34 CW PSC
T.E.
Ball
Franklin 76012, 80042, Electrohome EB4
7
R7-RB75
75
1/3000 115 0.55 CW SP
Open Sleeve
Electrohome 2899-010-001, EB75
8
R7-RB3
75
1/3220 115 0.34 CW PSC
Open Ball
Fasco B24220
9
R7-RB885
85
2/2800 115 0.65 CW SP
Open Sleeve
AO SMITH 414
10
R7-RB90
90
1/3000 115 1.00 CW SP
Open Sleeve
AO SMITH 13
11
R7-RB991
90
1/3000 115 1.00 CW SP
Open Sleeve
AO SMITH 383
12
Fig.1
Fig.5
Fig.6
Fig.8
Fig.2
Fig.3
Fig.4
Direct Drive Blowers
Fig.7
Fig.9
Fig.10
Fig.11
Fig.12
Flange Mounting Dimensions Available on Page 45 & 46
