Butt’s Pumps and Motors - page 1404

21
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
www.rotom.ca
Part # CFM Spd/RPM Volts Amps Rot. Type Const. Bearing Cross Fig
R7-RB265 265 1/1550 115 1.86 CCW SP Open Sleeve Franklin 80224, U.E.459, Fasco B45227 1
R7-RB266 265 1/1650 230 1.90 CCW SP Open Sleeve AO Smith 9411, Fasco B45227-2,
Grainger 4C869 2
R7-RB447 273 1/1640 115 0.77 CW PSC Open Ball Grainger 4C447, 1TDR3 3
R7-RB320 320 1/1500 115 1.30 CW SP Open Sleeve AO Smith 9486, Fasco 50756-D500 4
R7-RB326 326 1/1600 115 1.10 CCW PSC Open Ball AO Smith 9467, Grainger 4C943 5
R7-RB350 350 2/1570 115 3.00 CCW SP Open Sleeve AO Smith 9466, Grainger 4C444 6
R7-RB462 460 1/1550 230 1.80 CW SP Open Sleeve AO Smith 9412, Grainger 5C507 7
R7-RB465 465 1/1550 115 2.50 CCW SP Open Sleeve Franklin 80546, U.E.460, Fasco B45267,
Grainger 4C448 8
R7-RB495 495 1/1570 115 3.80 CCW SP Open Sleeve AO Smith 9465 9
R7-RB500 500 2/1550 115 3.50 CCW SP Open Sleeve AO Smith 9491, Fasco 50769-D500 10
R7-RB445 549 1/1430 115 2.20 CW PSC Open Ball Grainger 1TDT2, 4C445, 4YJ32 11
R7-RB760 760 2/1450 115 3.20 CW PSC Open Sleeve AO Smith 9459, Grainger 5C508 12
R7-RB1000 1000 2/1100 115/230 4.00 CCW PSC Open Sleeve AO Smith 9477, Fasco A1000 13
Direct Drive Blowers
Fig.1 Fig.2 Fig.3 Fig.4
Fig.5 Fig.6 Fig.7 Fig.8
Fig.9 Fig.10 Fig.11 Fig.12 Fig.13
Flange Mounting Dimensions Available on Page 45 & 46
