51
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Tyler
True
Trane (cont. from previous page)
Part # HP/ W Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
O4-R5715
15 W
115
0.37 PSC 1/1550 CW 3.50" 3.87"
Unit
-
Threaded
5215879, 5237801
10
O4-R5720
15 W
115
0.37 PSC 1/1550 Rev 3.50" 3.87"
Unit
-
Threaded
5212930
10
T1-R605
1/65
115
0.84 SP 1/2800 CW 0.88"
Skel
Sleeve
-
1.7" × 0.1811"
SM605, 79103, 79104,
E310131, P211116966A
11
R4-R3042
1/4
230
1.90 PSC 1/1625 CCW 4.61"
5.5"
Sleeve Inc.
2.5" × 1/2"
S3042, FASCO D870
12
Part # Watts Volts Amps Type RPM Rot. Body Dia BearingCap Shaft
Comments
Fig
O4-R5411
9
115 0.58 SP 1/1550 CW 2.80"
3.5"
Unit
- Threaded
936833, 800402
7
O4-R5401
9
115 0.60 SP 1/1550 CW 2.80"
3.5"
Unit
- Threaded
800401, All-angle evaporator motor
7
O4-R5730
9
115 0.26 PSC 1/1600 Rev 3.13"
3.5"
Unit
- Threaded
Reversible PSC condenser fan motor c/w wiring
harness for Pepsi
8
O4-R5811
16
115 1.00 SP 1/1550 CW 3.03"
3.5"
Unit
- Threaded
800469
9
Fig. 10
Fig. 11
Fig. 12
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap
Shaft
Comments Fig
Ue-955
1/6
115
2.00 PSC 3/1500 CW 4.0" 5.0" Sleeve
Inc.
10.5"×1/2"×10.5"
X70 500149-12-7,
MOT-1979, MOT-482, EM,
K48HXCKS-1418
1
R6-R46086
1/5
115
2.30 PSC 4/1075 CCW 4.18" 5.5" Sleeve 10/370
3.5"×1/2"
D340086P02
2
UE-642
1/4
277
1.10 PSC 3/1475 CW 4.0" 5.0" Sleeve
Inc.
8"×1/2"×8"
MOT 689, X70500354, UE
DE2G101
2
M2-R22983
1/4
200/230 1.50 PSC 1/825 CCW 4.62" 5.5"
Ball
12.5/370
2.5"×1/2"
3D146983P01, 1674,
K55DJL-6906
3
R6-R42604
1/3
575
0.80 PSC 1/1100 Rev 5.80" 5.5"
Ball
7.5/440
6" × 1/2"
MOT2604, 25G20
4
R6-R46126
1/3
115
6.80 PSC 4/1075 CCW 4.87" 5.5" Sleeve 10/370
3.0"×1/2"
D340126P02
2
R6-R42605
1/2
575
1.00 PSC 1/1625 Rev 5.60" 5.5"
Ball
7.5/440
6" × 1/2"
M02605, 173329, HF2J043
4
R6-R42606
1/2
575
1.10 PSC 1/1100 Rev 5.50" 5.5"
Ball
7.5/370
6" × 1/2"
TRANE, COMFORTAIRE
4
R6-R42607
3/4
575
1.60 PSC 1/1075 Rev 6.00" 5.5"
Ball
15/370
6" × 1/2"
HM3T071, MOT2607,
48A11T566
4
M5-S1454
1
208/230/460 2.4/4.8 PSC 3/1100 CW 4.0" 5.0" Sleeve 25/370
6"×5/8"
MOT2461
5
M5-T2538
1
208/230/460 4.10 3 Ph 3/1140 Rev 8.22" 6.5"
Ball
-
5.0"×5/8"
MOT2463
6
M5-T2540
1
575
1.70 3 Ph 1/1140 Rev 9.1" 6.5"
Ball
-
5.0"×5/8"
MOT2914
6
M5-S1456
1½
208/230/460 3.3/6.6 PSC 3/1100 Rev 3.25" 5.0" Sleeve 25/370
6"×5/8"
MOT2462
5
M5-T2542
1½
208/230/460 5.45 3 Ph 1/1140 Rev 10.1" 6.5"
Ball
-
5.0"×5/8"
MOT2464
6
M5-T2543
1½
575
2.20 3 Ph 1/1140 Rev 9.5" 6.5"
Ball
-
5.0"×5/8"
MOT1590
6
Fig. 5
Fig. 8
Fig. 9
Fig. 4
Fig.6
Fig.7
Fig. 1
Fig. 2
Fig. 3
OEM Replacement Motors
"N" - New Product
