Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Armstrong / B&G Direct Replacement
Single Shaft • Single Speed • 1725 RPM
115/230/460/575 Volts • Resilient Rings for Base Mount Models • Open Construction • Reversible
Typical Applications : Hot Water Boiler & Booster Pumps
Fig. 1
Fig. 5
Fig. 4
Fig. 3
Fig. 2
Fig. 7
Fig. 8
Fig. 10
Fig.9
Part # HP Volts Fig. Bearing
Cross Reference
CP-R1350
1/12
115
1
Ball
805316-010, 831000-61, 111034
CP-R1311
1/12
115
2 Sleeve
Taco Replacement
CP-R1320
1/8
115
3 Sleeve
CCW, 5KH32EG129GA, 48S17D1084
CP-R1310
1/8
115
4 Sleeve
OBG2004
CP-R1351
1/6
115
1
Ball
817025-005, 111061
CP-R1352
1/6
115
5
Ball
817025-001, 831001-061, 111031
CP-R1354
1/4
115
5
Ball
817025-007, 831002-061, 111040
CP-R1444
115
6
Ball
816141-001
CP-R1356
1/3
115
5
Ball
817025-013, 831003-061, 111042
CP-R1446
115
6
Ball
816141-002
CP-R1359
1/2
115/230 7
Ball
831009-061, 111044
CP-R1368
230/460 8
Ball
811757-003, 020, 023, 831011-083, 111046
CP-R1369
575
8
Ball
811757-004, 111046-5
CP-R1459
115/230 9
Ball
811757-001, 111044
CP-R1362
3/4
115/230 7
Ball
831010-062, 111047
CP-R1370
230/460 8
Ball
831012-083, 111049
CP-R1372
575
8
Ball
811757-006, 111049-5
CP-R1462
115/230 9
Ball
811757-002, 033, 111047
CP-R1470
230/460 10
Ball
811575-005, 111049
CP-R1472
575
10
Ball
811757-005, 024, 027, 111049-5
CP-R1363
1
115/230 7
Ball
816676-062, 111050
CP-R1371
230/460 8
Ball
816675-069, 169090
CP-R1373
575
8
Ball
816676-068, 169090-5
CP-R1463
115/230 9
Ball
811757-007, 028, 031, 111050
CP-R1471
230/460 10
Ball
811757-008, 169090
CP-R1473
575
10
Ball
811757-009, 028, 031, 169090-5
CP-R1365
1
1/2
115/230 7
Ball
816678-062, 169095
CP-R1374
230/460 8
Ball
816678-069, 169092
CP-R1375
575
8
Ball
816685-068, 196092-5
Part#
Specification
Description
T6-10010
1/2" × 1/2"
1/2 to 1/3 HP Easy Link
T6-10010SL
1/2" × 1/2"
Spirolink
T6-10023
1/2" × 1/2" or 1/2" × 5/8"
1/2 to 3/4 HP Easy Link
T6-10023SL
1/2" × 1/2" or 1/2" × 5/8"
Spirolink
T6-10034SL
1/2" × 5/8" or 5/8" × 5/8"
Spirolink
T6-10045SL
1/2" × 5/8" or 5/8" × 5/8"
Taco
T6-10010
Illustrated
Easy Links - Spirolink
T6-10034
Illustrated
CP-R1359
Illustrated
CP-R1463
Illustrated
CP-R1471
Illustrated
CP-R1373
Illustrated
Pump Couplers
Fig. 6
CP-R1350
Illustrated
CP-R1352
Illustrated
CP-R1310
Illustrated
CP-R1320
Illustrated
CP-R1311
Illustrated
CP-R1444
Illustrated
