4
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
Skeleton
Skeleton Motors
Skeleton Motors
Sleeve Bearing - Shaded Pole
Skeleton Motors continued from previous
3000 R.P.M.
Part #
Amps Volts HP Stack Rot.
Shaft
Rated Features
Comment
R635
0.80
208
230
1/40 1.50 C.W.
1.5"×1/4"
1700 RPM
0.95 Amps
1/75 HP
Cord c/w
spades
CHROMALOX,
WESTCAN
CONSTRUCTION
HEATER
R3555
0.85
115 1/80 0.65 C.W.
2.4"×7/32"
3000 RPM
0.85 Amps
1/80 HP
Cord & plug
BROAN NUTONE
65106,33-
106,C68627, EM-
555,SM-555,
VFM-106
R605
0.85
115 1/55 0.90 C.W.
1.7"×.1811"
2800 RPM
0.90 Amps
1/55 HP
30" cord
HUSSMAN
BLANCHARD
SM605, 79103,
79104, E310131,
P211116966A
R3551
0.90
115 1/45 0.90 C.C.W
1.4"×7/32"
3000 RPM
0.90 Amps
1/45 HP
C-ring groove,
three pin two
speed plug
BROAN NUTONE
656101, 33-101,
C52367, EM-551,
SM-551,
VFM-101
R610
0.90
115 1/50 0.90 C.W.
1.2"×7/32"
2400 RPM
1.00 Amps
1/60 HP
C- ring
groove, cord
w/ insulated
spades, 2 speed
BROAN NUTONE
27898, 64586, 64964,
67846,81734, 81795,
81798, 81800
R604
0.90
115 1/90 0.65 C.W.
1.2"×.181"
2700 RPM
0.92 Amps
1/85 HP
Cord & plug
BROAN, NUTONE
217A9871P2, 5007S,
5018S, SM604, 5030S,
04290001, 12657006
R3554
1.00
115 1/50 0.90 C.W.
1.5"×7/32"
3000 RPM
1.00 Amps
1/50 HP
C-ring groove,
three pin two
speed plug
BROAN NUTONE
65105, 33-105,
C27987,
EM-554, SM-554,
VFM-105
R684
1.00
115 1/70 0.80 C.C.W.
2.1"×7/32"
3000 RPM
1.00 Amps
1/70 HP
Cord & plug
NUVENT 2000A,
D90CB 2584SP, MR.
WHISPER
R607
1.10
115 1/35 1.15 C.C.W
1.7"×7/32"
2300 RPM
1.30 Amps
1/50 HP
Spades
HABCO CO21617
