Butt’s Pumps and Motors - page 1493

2
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end www.rotom.ca
Motors
Skeleton
Skeleton Motors
Skeleton Motors
Sleeve Bearing - Shaded Pole
3000 R.P.M.
Part # Amps Volts HP Stack Rot. Shaft Rated Features Comment
R670 0.45 115 1/130 0.65 C.C.W. 1.3"×3/16" 3000 RPM
0.45 Amps
1/130 HP
KIT-Cord &
plug c/w two
fan blades &
mounting kit
65670,14001,600,700,
710,EM-670,SM-670
R602 0.45 115 1/125 0.65 C.W.
1.6"×.1811" 3000 RPM
0.45 Amps
1/125 HP
Wire leads RAPID
REFRIGERATION
R603 0.45 115 1/110 0.65 C.W. 2.2"×7/32" 2400 RPM
0.52 Amps
1/125 HP
C-ring groove,
cord & plug
NUTONE
81058, 81096,
81795,81826, 81827,
81993,81994, 82230
R620 0.45
0.25
115
230 1/150 0.63 C.C.W. 1.5"×3/16" 3000 RPM
0.45 Amps
1/150 HP
Cord & plug +
1 lead, Dual
voltage
WESTWARD
14003, GEM EM671
R3670 0.45
0.25
115
230 1/150 0.63 C.C.W. 1.5"×3/16" 3000 RPM
0.45 Amps
1/150 HP
KIT-Cord &
plug c/w two
fan blades &
mounting kit
Dual Voltage
600, 602, 700, 702,
710,EM670, EM672,
14001, 14005
RF100-2 0.50 115 1/155 0.65 C.C.W. FAN
(low speed)
3000 RPM
0.55 Amps
1/260 HP
Bracket & blade
inc., Fireplace
blower, Two
Speed
ELECTROHOME
2811-581-002,EF100-2
R3100 0.50 115 1/130 0.65 C.W. 1.7"×7/32" 3000 RPM
0.50 Amps
1/130 HP
KIT-Cord & plug
c/w fan blade
BROAN NUTONE
65100, 33-100,
C65878,
EM-550,SM-550,VFM-
100
R619 0.50 115 1/130 0.50 C.W. 1.7"×7/32" 3000 RPM
0.50 Amps
1/130 HP
Cord & plug BROAN NUTONE
FASCO K111
R606 0.50 115 1/130 0.65 C.C.W. 1.1"×7/32" 3000 RPM
0.50 Amps
1/130 HP
Spades HABCO C021795
R613 0.50 115 1/125 0.65 C.W. 2.5"×7/32" 1600 RPM
0.55 Amps
1/260 HP
Two C-ring
grooves, cord &
plug
G.E. NUTONE
152B677B011, 64620
Skeleton Motors Continued on next page
Skeleton Motors continued from previous
