52
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Vanee
Venmar
W.W. Grainger - Dayton
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
R3-R348
1/15
110/115 1.12 PSC 1550 CW 4.0"
3.3"
Sleeve 4/370 3.25 × 5/16
HRV - M1703, 71900369
1
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap
Shaft
Comments Fig
R2-R462
1/8
115 0.90 PSC 3/1660 CW 4.13" 3.3"
Sleeve 7.5/370 3.5"×5/16"×3.5"
02101, Fasco 7190-2271, Kit
12027, 12029, 12109
2
R2-R422
1/3
115 2.89 PSC 3/1690 CW 4.93" 3.3"
Sleeve 7.5/370
3/8"×2.06"
02209, Fasco 7190-1522
3
R3-R366
1/4
115 1.68 PSC 3/1630 CW 4.78 3.3"
Sleeve 7.5/370 2.97"×3/8"×3.00"
02100, Fasco 7190-1523, Kit
1206, 12151
4
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap
Shaft
Comments Fig
R3-R373
1/15
115 0.90 PSC 1/1400 CCW 4.50"
3.3"
Sleeve 4/250
3.0"×3/8"
Dayton Greenhouse Fan Motor,
Fasco 7190-1004
5
O6-R499
1/15
115 1.00 PSC 1/1625 CCW 4.50"
3.3"
Sleeve 4/370
2.0"×5/16"
Grainger 3M499B
6
Fig. 5
Fig. 6
Fig. 7
Fig. 1
Fig. 2
Fig. 4
Fig. 3
York
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
M2-R25100
1/8
208/230 0.80 PSC 1/1075 CW 3.75" 5.5" Sleeve 4/370
1.8"×1/2"
F48A85A50, 3217,
024-25100-000, 024-2500-700
7
M4-R741
1/5
208/230 1.40 PSC 1/1075 CW 3.87" 5.0" Sleeve 5/370 6.3"×1/2"×6.3"
024-17774, 2091,
024-20795-700
8
M2-R23294
1/4
208/230 1.30 PSC 1/1075 CW 4.0" 5.5" Sleeve 5/370
3.0"×1/2"
F48A45A50, 3223,
024-23294-000
7
M2-R25119
1/4
208/230 1.40 PSC 1/850 CW 4.43" 5.5" Sleeve 5/370 3.18"×1/2"
F48B46A50, 024-25119-000
7
M2-R32160
1/4
208/230 2.00 PSC 1/1075 CW 4.0" 5.5" Sleeve 5/370
3.5"×1/2"
York 024-16076-700, GE
KCP39HG9433S
9
M4-R2679
1/4
115 10.00 SP 3/1075 CCW 4.0" 5.0" Sleeve
-
2.2"×1/2"
024-17903-703
10
M4-R2679
1/4
115 6.10 PSC 3/1075 CCW 4.09" 5.0" Sleeve 10/370 3.15"×1/2"
York Domestic Furnace
Motor 024-17903-005, GE
KCP29KK451BT
10
M2-R22275
1/4
460 0.70 PSC 1/850 CW 5.0" 5.5" Sleeve 5/350
3.0"×1/2"
York 024-27501-000, A.O.
Smith F4832A50
11
M2-R23238
1/2
208/230 2.50 PSC 1/1090 CW 4.87" 5.5" Sleeve 7.5/370 4.0"×1/2"
5KCP39LGN418S,
024-24110-001,
W48A11T388
12
R6-R45113
1/2
115 9.80 PSC 3/1110 CCW 5.37" 5.5" Sleeve 10/370 4.5"×1/2"
5KCP39NGP941S
024-25113-001
13
Fig. 8
Fig. 9
Fig. 11
Fig. 12
Fig. 10
Fig. 13
"N" - New Product
OEMReplacementMotors
