3
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
Skeleton
Skeleton Motors
Skeleton Motors
Sleeve Bearing - Shaded Pole
3000 R.P.M.
Part #
Amps Volts HP Stack Rot.
Shaft
Rated Features
Comment
R611
0.50
115 1/215 0.55 C.W.
1.7"×.1811"
1500 RPM
0.55 Amps
1/300 HP
C-ring
groove,Cord &
plug
ELECTROHOME
SM601,NUTONE
23303, BROAN
3008001
R634
0.50
208
230
1/40 1.10 C.C.W.
1.0"×7/32"
1730 RPM
0.60 Amps
1/90 HP
Cords c/w
spades
WESTCAN, DIMPLEX
R3550
0.60
115 1/115 0.55 C.W.
1.7"×7/32"
3000 RPM
0.60 Amps
1/115 HP
KIT-Cord & plug
c/w fan blade,
Rear mounting
BROAN NUTONE
65100, 33-100,
C65878,
EM-550,SM-550,VFM-
100
R3549
0.60
115 1/115 0.55 C.W.
1.7"×7/32"
3000 RPM
0.60 Amps
1/115 HP
KIT-Cord & plug
c/w fan blade,
Front mounting
Front Mounting R3550
R601
0.70
115 1/80 0.90 C.W.
2.2"×1/4"
3000 RPM
0.70 Amps
1/80 HP
Cord & plug
BROAN NUTONE
30080007, 162,
R3101
0.70
115 1/80 0.98 C.C.W.
1.6"×7/32"
3000 RPM
0.70 Amps
1/80 HP
Cord w/ three
pin two speed
plug
BROAN NUTONE
C52367,
C27987, EM551,
EM554,VFM101,
VFM105, R3551
R1014
0.70
115 1/65 0.88 C.W.
1.1"×3/16"
3000 RPM
0.70 Amps
1/65 HP
30" cord
BLANCHARD E1014,
KOOL AIR, REF PLUS,
CANCOIL
R3553
0.75
115 1/70 0.80 C.W.
1.8"×7/32"
3000 RPM
0.75 Amps
1/70 HP
Cord w/ ring
terminal
BROAN NUTONE
65104, 33-104,
C66582,
EM-552, SM-553,
VFM-104
R3103
0.75
115 1/70 0.80 C.W.
2.4"×7/32"
3000 RPM
0.75 Amps
1/70 HP
Cord & plug,
BROAN NUTONE
C63676, C66582,
C68626,27,EM552,553,
555,VFM103,104,106
R3552
0.80
115 1/55 0.90 C.W.
1.2"×7/32"
3000 RPM
0.80 Amps
1/55 HP
Cord & plug,
Ground wire
BROAN NUTONE
65105, 33-103,
C63675 EM-552, SM-
552,
VFM-103
Skeleton Motors continued from previous
Skeleton Motors Continued on next page
