Motors
Fan Coil Motors
Fan Coil Motors
Fan Coil Motors
Fan Coil Blowers
Thermo Aqua Stats
Temspec Fan Coil Motors
"A"
3 in 1
• 1/8 HP • 1/10 HP •
1/12 HP • 1000 RPM
• 115V • 5 Speed •
4.3" × 1/2" Shaft
Wiring Diagram
- 1/8 HP
- 1/10 HP
- 1/12 HP
Part #
CFM "A" Dim.
66-RFC300
300
6.75"
66-RFC400
400
8.25"
66-RFC600
600
9.0"
Direct Replacement For:
• Climetec
• Snyder-General
• Temspec
• Unilux
Comment:
UE799, L350, L450, L600, UE DA3E200, DA3F100, DA3G142, R2299
Heating & Air Conditioning • High Rise Apartment • Condominium • Hotel
Heating & Air Conditioning • High Rise Apartment • Condominium • Hotel
ONE MOTOR DOES ALL THREE! Bedroom, Living Room, Common Area.
M4-R2197
With 92-A8551 8.37" bracket
M4-R2195
Illustrated
M4-R2198
Motor Only
Replaces
• Unilux
• Temspec
• Climetec
• Snyder-General
Applications
• Heating & Air Conditioning
• High Rise Apartment
• Condominium
• Hotel
9" or 10" Bolt Circle
Thermo Aqua Stats
Part #
Description Specifications
Wires
Cross Ref
18-DT2-85
3 Wire Change
Over
Thermostats
Opens 83°F
Closes 65°F
2 term. Heating Only 54" × 5/8" mount.
37T31
18-DT3-85
3 term. Heating & Cooling 54" × 5/8" mount.
37T33
Comment:
UE & Tempspec DE3E142N
Part # HP Volts Amps Type
Cap.
RPM Rot. Body Frame Bearing Shaft
R2197
1/14
115 1.25 PSC/ Open 7.5/370 3/820 CCW 3.8"
5.0"
Sleeve 3.4"×1/2"
R2198
1/14
115 1.25 PSC/ Open 7.5/370 3/820 CCW 3.8"
5.0"
Sleeve 3.4"×1/2"
Comment:
M4-R2194 Temspec DE3E141N
M4-R2195 Temspec DE3F056N
M4-R2196 Temspec DE3G110N
Part # HP Volts Amps Type
Cap.
RPM Rot. Body Frame Bearing Shaft
R2194
1/14
115 1.25 PSC/ Open 7.5/370 3/820 CCW 4.0"
5.0"
Sleeve 3.4"×1/2"
R2195
1/12
115 2.10 PSC/ Open 7.5/370 3/740 CCW 4.6"
5.0"
Sleeve 3.4"×1/2"
R2196
1/8
115 2.50 PSC/ Open 7.5/370 3/850 CCW 4.5"
5.0"
Sleeve 3.9"×1/2"
Part #
HP Amps Cap.
RPM Body Shaft
DD-029
1/8
2.10 Inc.
5/1000 3.61" 1/2"×5.0"
DD-030
1/6
2.6 Inc.
5/950 3.57" 1/2"×4.5"
5KCP39DGV279S
