Butt’s Pumps and Motors - page 1582

91
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R6247
5W
1/1550
115
0.60
CW SP 3.5"
3.4"
Hubless
Condenser
1
R6243
6W
1/1550
115
0.60
CW SP 3.5"
3.4"
Hubless
Condenser
1
R6273
9W
1/1550
115
0.58
CW SP 3.5"
3.1"
Hubless
Condenser
1
R6203
15W
1/1550
115
0.60 CCW SP 3.9"
3.5"
7.0"×5/16"
Agitator
5
R6204
25W
1/1550
115
1.10 CCW SP 3.9"
3.5"
5.6"×5/16"
Agitator
5
R6205
25W
1/1550
115
1.10 CCW SP 3.9"
3.5"
7.0"×5/16"
Agitator
5
R6206
50W
1/1550
115
1.70
CW SP 3.9"
3.5"
3.0"×5/16"
134350000,
ESPOL05OEM B1
5
Cornelius - QBD
Fig.5
Fig.6
Copeland
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R5311
6W
1/1550
120
0.36
CW SP 3.5"
2.8"
HUBLESS
GE5311
1
R5421
9W
1/1550 208/230 0.29
CW SP 3.5"
2.8"
HUBLESS
GE5421
1
R5411
9W
1/1550
120
0.58
CW SP 3.5"
2.8"
HUBLESS
GE5411
1
R3512
35W
1/1550 208/230 0.70
CW SP 3.8"
3.5"
HUBLESS
050-0227-02
2
R3511
35W
1/1550
120
1.40
CW SP 3.8"
3.5"
HUBLESS
050-0227-01
2
R5012
50W
1/1550 208/230 0.85
CW SP 3.8"
4.5"
HUBLESS
050-0017-01
1
R5022
50W
1/1550 208/230 0.85 CCW SP 3.8"
4.5"
HUBLESS
050-0011-00
1
R3047
1/4
1/1625 208/230 1.50
CW 5/370 5.5"
4.30"
2.5" × 1/2"
050-0107-01, 0238-00 3
R3005
1/3
1/825 208/230 2.40
CW 5/370 5.5"
5.00"
3.5" × 1/2"
050-0234-00, 0107-02 3
S1502
1/3
1/1075
200/230
460
1.40
Rev 5/440 5.5"
7.30"
3.5" × 1/2"
050-0015-00, 0105-00 4
T1536
3/4
1/1140
575
1.50
Rev 3 Ph 5.5" 11.00"
4.0" × 5/8"
050-0169-00,01,0236-00 4
Fig.1
Fig.3
Fig.4
Fig.2
