Panels & Controls
17
E
Professional Plumbing
Specifications:
CORD
:
P/N 125150:
.....18/2 SJOW
P/N 125151:
.....16/2 SJOW
PLUG
.......................................125 VAC NEMA 5-15 Piggy-Back Plug
FLOAT
.....................................Polypropylene for use in water & sewage up to
140° (60° C).
WATER DEPTH
.......................Maximum 30' (9m), 13 PSI
SWITCH
..................................Snap Action, Normally Open
CLAMP
....................................Stainless Steel Construction. Range: 1" to 3" Dia.
MOUNTING SADDLE
.............ABS/Nylon
SWITCH COMPONENT ELECTRICAL RATINGS:
P/N 125150, 125 VAC:
............Maximum Electrical Load: 10.0 Amps
Maximum Starting Current: 60.0 Amps
Minimum Electrical Load: 100.0 Milliamps @ 12 VAC
P/N 125151, 125 VAC:
............Maximum Electrical Load: 13.0 Amps
Maximum Starting Current: 78.0 Amps
Minimum Electrical Load: 100.0 Milliamps @ 12 VAC
ELECTRICAL CONFIGURATION:
.................................................Normally Open
COLOR
....................................Black
PACKING
................................Pack Float Assembly, Clamp, Saddle &
Instruction Sheet in Individual Carton.
inches
(mm)
P/N: 125150
125151
Control Float
Piggy-Back In-Line Floats
125 Volt
PART NUMBER CORD LENGTH TYPE INSTALLATION CONTACTS
125150
10', 20', 30'
Pipe Mounted
125 Volt
OPEN
125151
15', 20', 30', 50'
Pipe Mounted
125 Volt
OPEN
