SECTION
PAGE
DATE
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
Panels & Controls
9
E
Professional Plumbing
ALARM
Water-tight, Indoor/Outdoor
120 Volt
8/09
P/N: 126307
inches
(mm)
VOLTAGE......................
Primary 120V, 50/60Hz
ENCLOSURE................
Water-tight, Thermoplastic, Type 3R
ALARM HORN..............
85db (A) at 10ft.(3m)
ALARM LIGHT..............
Top Mounted type 4X
ALARM FLOAT.............
High impact resistant PVC Housing,
Mechanical tilt switch hermetically sealed
with 15ft. (5m) 18/2 SJOW water resistant
neoprene (CPE) cord with pipe clamp.
TEMPERATURE RATING:
140°F (60°C)
This Alarm System includes a water-tight panel with a top mounted
Alarm light, a test/silence switch, a power on light and a 85db (A)
alarm horn with a mercury float.
The liquid level alarm system is designed specifically for lift pump
chambers and sump pump basins. The float switch is lowered into
the tank and secured at the desired alarm level. When the liquid
rises (high level alarm) or lowers (low level alarm), the float tips
and activates the horn and light on the alarm panel.
