Professional Plumbing
Specifications:
CORD
......................................18/2 SJOW
PLUG
.......................................None
FLOAT
.....................................Polypropylene for use in water & sewage up to
140° (60° C).
WATER DEPTH
.......................Maximum 30' (9m), 13 PSI
SWITCH
:
P/N 125148:
.....Snap Action, Normally Open
P/N 125149:
.....Snap Action, Normally Closed
CLAMP
....................................Stainless Steel Construction. Range: 1" to 3" Dia.
MOUNTING SADDLE
.............ABS/Nylon
SWITCH COMPONENT ELECTRICAL RATINGS:
125/250 VAC:
...Maximum Electrical Load: 5.0 Amps
Minimum Electrical Load: 100.0 Milliamps @ 12 VAC
ELECTRICAL CONFIGURATION:
P/N 125148:
.....Normally Open
P/N 125149:
.....Normally Closed
COLOR
....................................Black
PACKING
................................Pack Float Assembly, Clamp, Saddle &
Instruction Sheet in Individual Carton.
inches
(mm)
P/N: 125148
125149
Control Float
Pilot Duty
125/250 Volt
PART NUMBER CORD LENGTH TYPE INSTALLATION CONTACTS
125148
15', 30', 50', 100'
Pipe Mounted
125/250 Volt
OPEN
125149
15', 30', 50', 100'
Pipe Mounted
125/250 Volt
CLOSED
7/08
