Professional Plumbing
Control Float
Direct Control
120/230 Volt
P/N: 125153
Specifications:
CORD
......................................16/2 SJOW
PLUG
.......................................None
FLOAT
.....................................Polypropylene for use in water & sewage up to
140° (60° C).
WATER DEPTH
.......................Maximum 30' (9m), 13 PSI
SWITCH
..................................Snap Action, Normally Open
CLAMP
....................................Stainless Steel Construction. Range: 1" to 3" Dia.
MOUNTING SADDLE
.............ABS/Nylon
SWITCH COMPONENT ELECTRICAL RATINGS:
120 VAC:
..........Maximum Electrical Load: 13.0 Amps
Maximum Pump Starting Current: 78.0 Amps
Minimum Electric Load: 100.0 Milliamps @ 12 VAC
230 VAC:
..........Maximum Electrical Load: 13.0 Amps
Minimum Electrical Load: 100.0 Milliamps @ 12 VAC
ELECTRICAL CONFIGURATION:
.................................................Normally Open
COLOR
....................................Black
PACKING
................................Pack Float Assembly, Clamp, Saddle &
Instruction Sheet in Individual Carton.
inches
(mm)
PART NUMBER CORD LENGTH TYPE INSTALLATION CONTACTS
125153
15', 30', 50', 100'
Pipe Mounted
120/230 Volt
OPEN
7/08
