Professional Plumbing
Control Float
Piggy-Back In-Line Floats
240 Volt
P/N: 125152
125154
inches
(mm)
Specifications:
CORD
:
P/N 125152:
.....16/2 SJOW
P/N 125154:
.....14/2 SJOW
PLUG
:
P/N 125152:
.....240 VAC NEMA 5-15 Piggy-Back Plug
P/N 125154:
.....240 VAC NEMA 6-15 Piggy-Back Plug
FLOAT:
P/N 125152:
.....Polypropylene for use in water & sewage up to
140° (60° C).
P/N 125154:
.....PVC for use in water & sewage up to 140° (60° C).
WATER DEPTH
.......................Maximum 30' (9m), 13 PSI
SWITCH
..................................Snap Action, Normally Open
CLAMP
....................................Stainless Steel Construction. Range: 1" to 3" Dia.
MOUNTING SADDLE
.............ABS/Nylon
SWITCH COMPONENT ELECTRICAL RATINGS:
P/N 125152, 240 VAC:
............Maximum Electrical Load: 13.0 Amps
Maximum Starting Current: 78.0 Amps
Minimum Electrical Load: 100.0 Milliamps
P/N 125154, 240 VAC:
............Maximum Electrical Load: 15.0 Amps
Maximum Starting Current: 85.0 Amps
Minimum Electrical Load: 100.0 Milliamps
ELECTRICAL CONFIGURATION:
.................................................Normally Open
COLOR
:
P/N 125152:
.....Black
P/N 125154:
.....Grey
LOGO
......................................None
PACKING
................................Pack Float Assembly, Clamp, Saddle &
Instruction Sheet in Individual Carton.
PART NUMBER CORD LENGTH TYPE INSTALLATION CONTACTS
125152
15', 20', 30', 50'
Pipe Mounted
240 Volt
OPEN
125154
15', 20', 30', 50'
Pipe Mounted
240 Volt
OPEN
7/08
