Butt’s Pumps and Motors - page 960

phone: 1-800-678-7178 fax: 1-800-270-9342
- 227 -
Central Spa
&
Pool Supply Ltd.
© 2012
WATERWAY
P
OOL
P
ARTS
SVL56 HIGH-FLOW PUMP
SKU Number
Description
List Price
Code
1
511-1310
................ Trap Lid.......................................................................$ 62.68
B
2
805-0439
................ Trap Lid O-Ring...........................................................$
7.64
B
3
319-1310
................ Basket Assembly.........................................................$ 28.48
B
4
315-1300
................ Volute Housing............................................................$ 359.70
B
5
310-7470
................ Diffuser - High Pressure..............................................$ 88.98
B
310-3300
................ Diffuser - High Flow.....................................................$ 88.48
B
6
805-0238
................ Diffuser O-Ring ...........................................................$
4.08
B
7
819-0018
................ Diffuser Screw (2 required) .........................................$
2.68
B
8
IMPELLER ASSEMBLIES - HIGH PRESSURE
310-7400
................ SVLHPS-107...............................................................$ 73.00
B
310-7410
................ SVLHPS-110...............................................................$ 73.00
B
310-7420
................ SVLHPS-115, SVLHPS-215........................................$ 73.00
B
310-7430
................ SVLHPS-120, SVLHPS-220 .......................................$ 73.00
B
310-7440
................ SVLHPS-125, SVLHPS-225 .......................................$ 73.00
B
310-7450
................ SVLHPE-130...............................................................$ 73.00
B
8
IMPELLER ASSEMBLIES - HIGH FLOW
310-3670
................ SVL56S-120, SVL56S-125 .........................................$ 73.00
B
310-3680
................ SVL56S-130................................................................$ 73.00
B
9
820-0017
................ 3/8” Flat Washer (12 required)....................................$
1.00
B
10
819-4360
................ Screw, Left Hand Thread ............................................$
5.20
B
11
711-4300
................ Gasket, Left Hand Screw ............................................$ 10.32
B
12
819-0013
................ Screw (2 required) ......................................................$
1.70
B
13
715-1201
................ Drain Plug ...................................................................$
2.94
A
14
805-0112
................ Drain Plug O-Ring.......................................................$
0.72
B
15
672-1300
................ SVL56 Base ................................................................$ 64.82
B
16
672-1310
................Motor Support .............................................................$ 14.26
B
17
311-1400
................ Volute Faceplate .........................................................$ 104.56
B
18
711-4290
................ Faceplate Gasket........................................................$ 21.78
B
SUPREME PUMP
SKU Number
Description
List Price
Code
1
511-1310
................ Trap Lid.......................................................................$ 62.68
B
2
805-0439
................ Trap Lid O-Ring...........................................................$
7.64
B
3
319-1530
................ Trap Basket.................................................................$ 22.38
B
4
715-1201
................ Drain Plug ...................................................................$
2.94
A
5
805-0112
................ Drain Plug O-Ring.......................................................$
0.72
B
6
805-0001-SPL
........ Face Plate Volute O-Ring ...........................................$
3.16
B
7
310-5100
................ Impeller, 1.5 HP...........................................................$ 49.34
B
1
2
3
4
7
9 17
6
5
10 & 11
16
12
14
13
15
18
8
1
2
3
4
6
7
5
