POOL PARTS STA-RITE
CHECK YOUR ORDER ACKNOWLEDGEMENT FOR AVAILABILITY OF PARTS
1
5B
4
17
16
9
7
6
11
12
13
14
8
10
15
5A 2
3
MODELS
S7MD60
S7MD72
SYSTEM 3 MODULAR FILTER - SMD SERIES
SKU Number Description List Price Code
1 154689 ................... Air Release Valve........................................................$ 31.12 B
2 24900-0504 ............ Adapter Bushing .........................................................$ 18.76 B
3 35505-1423 ............ O-Ring.........................................................................$ 2.06 B
4 24850-0008 ............ Tank O-Ring ................................................................$ 66.28 B
5A 25023-0160S .......... Replacement Module – S7MD60 ................................$ 664.06 B
25023-0172S .......... Replacement Module – S7MD72 ................................$1,100.64 B
27002-0100S .......... Replacement Module System 2 - PLM100 .................$ 295.34 B
5B 24800-0120 ............ Air Bleed Assembly .....................................................$ 22.16 B
6 23910-0013S .......... Baffle Kit with Screws .................................................$ 36.00 B
7 23910-0100S .......... Elbow and Bulkhead Assembly...................................$ 126.00 B
8 35505-7438 ............ O-Ring.........................................................................$ 9.76 B
9 23910-0101S .......... Deflector and Bulkhead Assembly ..............................$ 84.00 B
10 35505-1425 ............ O-Ring (2 required) .....................................................$ 15.54 B
11 27001-0022 ............ 1½” Plug with O-Ring..................................................$ 2.96 B
12 24900-0509 ............ Adapter Fitting.............................................................$ 28.86 B
13 35505-1424 ............ O-Ring (2 required) .....................................................$ 9.62 B
14 24900-0503 ............ Drain Plug ...................................................................$ 28.66 B
15 24752-0050 ............ Bulkhead Retaining Nut (2 required)...........................$ 24.80 B
16 24850-0010 ............ Clamp Bolt (7 required)...............................................$ 31.80 B
17 24850-0200 ............ Clamp Assembly (7 required)......................................$ 131.24 B
5A
MODELS
S7M120
S7M400
S8M150
S8M500
1
17
16
4
2
5B
3
10
11
12 13
13
14
15
SYSTEM 3 MODULAR FILTER - SM SERIES
SKU Number Description List Price Code
1 33600-0023T .......... Pressure Gauge..........................................................$ 49.44 B
2 24900-0504 ............ Adapter Bushing .........................................................$ 18.76 B
3 35505-1423 ............ O-Ring.........................................................................$ 2.06 B
4 24850-0008 ............ Tank O-Ring ................................................................$ 66.28 B
5A 25022-0201S .......... Replacement Large Cartridge – S7M120 ...................$ 565.80 C
25022-0224S .......... Replacement Large Cartridge – S7M400 ...................$ 774.36 C
5B 25021-0200S .......... Replacement Small Cartridge – S7M120....................$ 284.74 C
25021-0223S .......... Replacement Small Cartridge – S7M400....................$ 315.56 C
10 35505-1425 ............ O-Ring (2 required) .....................................................$ 15.54 B
11 27001-0022 ............ 1½” Plug with O-Ring..................................................$ 2.96 B
12 24900-0509 ............ Adapter Fitting.............................................................$ 28.86 B
13 35505-1424 ............ O-Ring (2 required) .....................................................$ 9.62 B
14 24900-0503 ............ Drain Plug ...................................................................$ 28.66 B
15 24752-0050 ............ Bulkhead Retaining Nut (2 required)...........................$ 24.80 B
16 24850-0010 ............ Clamp Bolt (7 required)...............................................$ 31.80 B
17 24850-0200 ............ Clamp Assembly (7 required)......................................$ 131.24 B
