POOL PARTS WATERWAY
CLEARWATER SAND FILTER
SKU Number Description List Price Code
1 WVS002 .................Multi-Port Valve Assembly Clamp Style ......................$ 146.02 B
(2001 and before)
1B WVS003 .................Multi-Port Valve Assembly with Split-Nut ...................$ 146.02 B
2 711-1920 ................ Collar Gasket (use with Clamp Style) ........................$ 14.56 B
(2001 & before)
2B 805-0435 ................Multi-Port O-Ring (use with Split-Nut Style)................$ 8.88 B
3 505-2070 ................ Collar Assembly - Clamp Style....................................$ 50.76 B
3B 505-3000 ................ Threaded Sleeve Assembly ........................................$ 22.96 B
3C 505-3010 ................ Split-Nut ......................................................................$ 25.52 B
4 LATERAL & MANIFOLD ASSEMBLY
505-2040 ................ for 16” Filter.................................................................$ 100.74 B
505-2050 ................ for 19” Filter.................................................................$ 95.08 B
505-2060 ................ for 22” Filter.................................................................$ 95.08 B
505-2080 ................ for 26” Filter.................................................................$ 95.08 B
5 505-1930 ................ Lateral-Thread Style (2003 & Before) .........................$ 7.88 B
505-1950 ................ Lateral-Twist Style (2004) ...........................................$ 7.88 B
6 505-2020 ................ Drain Assembly ...........................................................$ 18.04 B
7 505-2030 ................ Drain Cap Assembly ...................................................$ 8.20 B
8 425-1928 ................Waste Adapter Fitting..................................................$ 17.58 B
9 505-1970 ................ Collar Wrench for Threaded Style Split-Nut................$ 20.90 B
10 672-7211 ................ Base............................................................................$ 88.64 B
11 805-0224 ................ O-Ring 1½” .................................................................$ 0.84 A
CAREFREE SAND FILTER
SKU Number Description List Price Code
1 WVS003 .................Multi-Port Valve Assembly with Split Nut.....................$ 146.02 B
2 PG-30 ..................... PSI Gauge ..................................................................$ 6.04 B24-10
3 505-3000 ................ Threaded Sleeve Assembly ........................................$ 22.96 B
3A 505-3010 ................ Split Nut ......................................................................$ 25.52 B
4 505-1930 ................ Lateral - Thread Style (2003 & Before) .......................$ 7.88 B
519-5370 ................ Lateral - 22” & 26” Sand Filters...................................$ 9.70 B
5 425-1928 ................Waste Adapter Fitting..................................................$ 17.58 B
6 505-1970 ................ Collar Wrench .............................................................$ 20.90 B
7 602-5310 ................ Self-threading Drain Screen........................................$ 6.24 B
8 602-5301 ................ Drain Screen Cap .......................................................$ 5.92 B
9 672-7211 ................ Base............................................................................$ 88.64 B
10 417-4161 ................ Buttress, 1½” x 1½”MPT .............................................$ 5.86 B
11 502-2011 ................ Sand Fill Guide ...........................................................$ 7.24 B
12 LATERAL & MANIFOLD ASSEMBLY
505-2150 ................ Lateral and Manifold Assembly, 19” ............................$ 95.08 B
505-2160 ................ Lateral and Manifold Assembly, 22” ............................$ 95.08 B
505-2180 ................ Lateral and Manifold Assembly, 26” ............................$ 95.08 B
13 805-0224 ................ O-Ring 1½” .................................................................$ 0.84 A
14 711-4000 ................ Gasket 1½” .................................................................$ 0.84 A
1
2 & 2B
3
4
5
6
7
10
11 8
1B
3C
9
3B
1 2
4
3
11
7
13
8
5
6
3A 12
10
14
13
9
