Butt’s Pumps and Motors - page 956

phone: 1-800-678-7178 fax: 1-800-270-9342
www.centralspasupply.com - 223 - Central Spa & Pool Supply Ltd.
© 2012
STA-RITE POOL P ARTS
MAX-E-GLAS / DURA-GLAS
SKU Number Description List Price Code
1 17351-0009 ............Water Slinger ..............................................................$ 2.00 C
2 C203-193P ............. Seal Plate Kit ..............................................................$ 178.74 C
3 U9-228A ................. O-Ring.........................................................................$ 10.10 B
4 17304-0100S.......... Shaft Seal ...................................................................$ 12.50 B
5 WC36-22 ................ Clamp Knob ................................................................$ 14.14 C
5A C19-37A ................. Clamp..........................................................................$ 111.34 B
6 C105-92PR............. Impeller 1/2 HP ...........................................................$ 74.26 B
7 C1-216P ................. Diffuser 1/2 HP............................................................$ 31.40 B
C1-200-PA.............. Diffuser 3/4 - 2.5 HP....................................................$ 33.34 C
C1-259P ................. Diffuser 3 HP...............................................................$ 33.34 B
8 U30-542SS ............. Screw ..........................................................................$ 2.40 C
9 U43-21SS............... Lock Washer ...............................................................$ 2.00 C
10 U9-226.................... Diffuser O-Ring ...........................................................$ 2.28 B
11 C176-47P1 ............. Tank Body ...................................................................$ 142.34 C
12 U178-920P ............. Drain Plug with O-Ring ...............................................$ 3.56 C
12A U9-359.................... Drain Plug O-Ring.......................................................$ 0.84 B
13 C35-11....................Motor Pad ...................................................................$ 3.44 B
15
16
17
11
1 & 1A
2
3
8
4
5
6
7
9
10
18 14 19
20
12
13
3
2
1
4
5
6
7
MAX-E-GLAS II / DURA-GLAS II
SKU Number Description List Price Code
1 U30-692SS ............. Screw ..........................................................................$ 2.40 C
1A U43-22SS ............... Lockwasher.................................................................$ 2.04 B
2 U17-568.................. Bonding Lug................................................................$ 11.64 C
3 17351-0009 ............Water Slinger ..............................................................$ 2.00 C
4 C203-194P ............. Seal Plate Kit ..............................................................$ 178.74 B
5 U9-228A ................. O-Ring.........................................................................$ 10.10 B
6 SEAL-02................. Seal, 3/4 #201 ............................................................$ 11.32 A12-10
7 WC36-22 ................ Clamp Knob ................................................................$ 14.14 C
8 C19-37A ................. Clamp..........................................................................$ 111.34 B
9 Call for Proper Matching of Impeller
10 C1-271P1 ............... Diffuser 3/4 & 1 HP .....................................................$ 34.10 B
C1-271P ................. Diffuser 1.5 - 3 HP.......................................................$ 32.94 B
11 U9-374 .................... Diffuser O-Ring ...........................................................$ 5.28 B
12 U43-21SS ............... Lockwasher.................................................................$ 2.00 C
13 U30-542SS ............. Diffuser Screw.............................................................$ 2.40 C
U30-922SS ............. Diffuser Screw, 1.5 - 3HP............................................$ 1.16 C
14 C176-59P ............... Tank Body Assembly...................................................$ 300.84 B
15 C3-185P ................. Trap Cover ..................................................................$ 65.66 C
16 U9-375 .................... Trap Cover O-Ring......................................................$ 15.06 B
17 C8-58P ................... Basket .........................................................................$ 14.70 C
18 U178-920P ............. Drain Plug with O-Ring ...............................................$ 3.56 C
19 U30-918SS ............. Screw for Base............................................................$ 5.44 B
20 C35-43 ....................Motor Pad ...................................................................$ 5.80 B
SUCTION TRAP ASSEMBLY
SKU Number Description List Price Code
1 C3-139P1 ............... Cover ..........................................................................$ 61.66 B
2 U9-229 .................... O-Ring, Cover .............................................................$ 12.18 B
3 C108-33P ............... Strainer Basket ...........................................................$ 13.64 B
4 C153-53P1 ............. Trap Body....................................................................$ 118.80 B
5 C20-123.................. Gasket.........................................................................$ 8.96 B
6 U178-920P ............. Drain Plug ..................................................................$ 3.56 C
7 U9-359 .................... Drain Plug O-Ring.......................................................$ 0.84 B
1 2
3 5
6
4 13
5A 9
8
11
12A
12
10
7
