Butt’s Pumps and Motors - page 958

phone: 1-800-678-7178 fax: 1-800-270-9342
www.centralspasupply.com - 225 - Central Spa & Pool Supply Ltd.
© 2012
7
3
6
8
12
1
11
10
8
9
4
5
STA-RITE POOL P ARTS
MULTI-PORT DIAL VALVE 1 1/2”
SKU Number Description List Price Code
1 14962-0032 ............ Handle.........................................................................$ 16.30 B
2 35857-0021 ............ Dowel Pin....................................................................$ 7.20 B
3 14965-0007 ............Washer........................................................................$ 4.10 B
4 35505-1228 ............ O-Ring.........................................................................$ 3.64 B
5 14965-0006 ............ Spring..........................................................................$ 17.80 B
6 33600-0023T .......... Pressure Gauge..........................................................$ 49.44 B
7 14965-0028 ............ Plug and Gasket Assembly .........................................$ 55.80 B
8 35505-1275 ............ O-Ring, Cover .............................................................$ 6.24 B
9 35407-0071 ............ Nut ..............................................................................$ 5.44 B
10 U9-369.................... O-Ring, Tank Flange ...................................................$ 15.86 C
MULTI-PORT TOP MOUNT DIAL VALVE
SKU Number Description List Price Code
1 14962-0017 ............ Plug with Gasket .........................................................$ 108.00 B
3 35407-4297 ............ Hex Nut, 1/4-20 SS .....................................................$ 3.56 B
4 14962-0021 ............ Square Ring, Buna-N..................................................$ 21.74 C
5 15060-0000T .......... Pressure Gauge - 0-60PSI..........................................$ 49.44 B
6 U30-74SS............... Bolt, 3/8-16 x 1” SS.....................................................$ 4.70 B
7 35857-0021 ............ Dowel Pin, 5/16 x 2-1/2” SS........................................$ 7.20 B
8 14962-0005 ............Washer........................................................................$ 4.30 B
9 35505-1228 ............ O-Ring.........................................................................$ 3.64 B
10 14962-0011 ............ Compression Spring ...................................................$ 21.30 B
11 35505-1272 ............ O-Ring.........................................................................$ 10.04 B
12 77704-0102 ............ Plug and Cover Assembly...........................................$ 253.84 B
3
6
2
4
3
5
3
7
8
10
9
1
PANTERA SAND FILTER
SKU Number Description List Price Code
1 WC137-516P.......... Collector Hub Assembly..............................................$ 113.06 B
2 23910-0005 ............ Base............................................................................$ 182.74 B
3 14962-0021 ............ Square Ring ................................................................$ 21.74 C
4 U43-62SS............... 3/8” Flat Washer..........................................................$ 2.00 C
5 U30-74SS............... Bolt, 3/8” x 16 x 1”.......................................................$ 4.70 B
6 24700-0075 ............ Lateral .........................................................................$ 16.06 B
2
9
6
8
5
1
3
4
7
3 & 4
5
1
6
2
CRISTAL-FLO SAND FILTER
SKU Number Description List Price Code
1 U9-369.................... O-Ring, Valve Flange..................................................$ 15.86 C
2 WC19-87A.............. V-Clamp ......................................................................$ 169.24 B
3 WC36-22 ................ Clamp Knob ................................................................$ 14.14 C
4 24200-0110 ............ Collector Hub Assembly..............................................$ 110.60 B
5 U9-370.................... O-Ring, Lateral............................................................$ 1.64 B
6 24600-0003 ............ Drain Lateral ...............................................................$ 10.30 B
7 21180-0100 ............ Lateral T-300BP-2.......................................................$ 24.80 B
8 U9-371.................... Drain Cap, O-Ring ......................................................$ 3.00 B
9 14965-0025 ............ Drain Cap....................................................................$ 30.20 B
