POOL PARTS WATERWAY
IN-LINE CHLORINATOR
SKU Number Description List Price Code
1 519-1167 ................ Lid (2002 - 2007 & 2007 & Later)................................$ 22.42 B
519-1181 ................ Lid (Prior to 2002) .......................................................$ 22.42 B
2 805-0348V .............. Lid O-Ring (2002 - 2007 & 2007 & Later) ...................$ 12.82 B
805-0340V .............. Lid O-Ring (Prior to 2002)...........................................$ 14.06 B
3 411-1170 ................. 90° Elbow - 1/4” Pipe (2002 - 2007 & 2007 & Later)...$ 5.06 B
4 600-1207 ................ Dial Stem Assembly (2007 & Later) ............................$ 28.70 B
5 805-0113V .............. O-Ring - Viton (2002 - 2007 & 2007 & Later)..............$ 2.00 B
6 600-1180 ................ Check Valve Assembly (2002-2007 & 2007 & Later) ..$ 12.56 B
7 600-1190 ................ Stem Assembly with O-Ring (2002 - 2007).................$ 28.68 B
MULTI-PORT VALVE ASSEMBLY
SKU Number Description List Price Code
1 600-9600 ................Multi-Port Lid Assembly ..............................................$ 128.70 B
2 600-9500 ................ Diverter Valve Assembly with Gasket..........................$ 49.02 B
3 805-0254 ................ Lid O-Ring (2001 & Before) ........................................$ 9.62 B
4 602-1931 ................ Lid Handle Only ..........................................................$ 12.94 B
5 711-1910B .............. Diverter Gasket (Spider) .............................................$ 22.14 B
(NOTE: We recommend purchasing gasket glued into diverter by the factory)
6 819-0010 ................ Lid Screw ....................................................................$ 2.48 B
7 820-0013 ................ Hex Nut .......................................................................$ 2.54 B
8 800-0100 ................ Split-Nut Bolt & Nut .....................................................$ 4.86 B
9 800-0150 ................ O-Ring Kit with Pin & Washer .....................................$ 15.32 B
10 827-0002 ................ Spring..........................................................................$ 9.06 B
2007 and LATER
PRIOR to 2002 2002 - 2007
1
1
2
6
1
2
6
5
7
5
4
6
1
7
8
3
9
10
5
2
4
3 2
3
