Butt’s Pumps and Motors - page 964

phone: 1-800-678-7178 fax: 1-800-270-9342
www.centralspasupply.com - 231 - Central Spa & Pool Supply Ltd.
© 2012
WATERWAY POOL P ARTS
RENEGADE SKIMMER
SKU Number Description List Price Code
1+3 540-6470WW ......... Lid, Skimmer Renegade - White .................................$ 26.42 B
1 519-6460 ................ Blank Insert - White.....................................................$ 3.12 B
1 519-6467 ................ Blank Insert - Grey ......................................................$ 3.12 B
2 819-0005 ................ Screw #8-32 x 7/16”....................................................$ 0.78 B
3 519-6450 ................ Lid - White...................................................................$ 29.22 B
3 519-6457 ................ Lid - Grey ....................................................................$ 29.22 B
4 519-6420 ................ Lid Mounting Ring .......................................................$ 22.60 B
5 519-3250 ................ Basket Handle.............................................................$ 2.84 B
6 519-6570 ................Mounting Ring Extension ............................................$ 12.44 B
7 519-3240 ................ Basket 8.12” Diameter x 5.25” H.................................$ 12.28 B
5+7 542-3240 ................ Basket Assembly with Handle - White ........................$ 16.36 B
8 519-6440 ................ Basket Mounting Ring.................................................$ 9.84 B
9 519-6400 ................ Upper Body .................................................................$ 85.58 B
10 519-6350 ................Weir Door Hinge..........................................................$ 22.82 B
11 550-9950 ................Weir, Simmer Renegade - White.................................$ 26.42 B
11 550-9959-DKG .......Weir, Simmer Renegade - Dark Grey .........................$ 26.34 B
12 865-0200 ................ Foam...........................................................................$ 1.44 B
13 519-6320 ................Weir Door Stop............................................................$ 22.82 B
14 819-4350 ................ Screw 8 x ⅝” ...............................................................$ 0.50 B
15 519-6470 ................ Diverter Plate ..............................................................$ 6.28 B
16 519-6410 ................ Lower Body 2½” Spigot x 2” Slip x 2” NPT..................$ 113.02 B
RENEGADE VINYL LINER / FIBERGLASS SKIMMER
SKU Number Description List Price Code
1 519-6460WW ......... Logo Lid Insert ............................................................$ 3.12 B
2 819-0005 ................ Screw #8-32 x 7/16”....................................................$ 0.78 B
3 519-9500 ................ Square Lid - White ......................................................$ 15.04 B
3 519-9507 ................ Square Lid - Grey........................................................$ 15.04 B
3a 540-6491WW ......... Lid - Black with Logo Insert.........................................$ 32.62 B
4 519-6480 ................ Vacuum Plate..............................................................$ 23.16 B
5 519-3250 ................ Basket Handle.............................................................$ 2.84 B
6 519-3240 ................ Basket 8.12” Diameter X 5.25” H (no handle).............$ 12.28 B
7 820-4110 ................ Screw Lock .................................................................$ 0.28 B
8 519-9510 ................ Square Collar - White..................................................$ 24.00 B
8 519-9517 ................ Square Collar - Grey ...................................................$ 27.22 B
9 519-6440 ................ Basket Mounting Ring.................................................$ 9.84 B
10 519-6560 ................Mounting Ring Extension ............................................$ 15.02 B
11 519-6570 ................Mounting Ring Extension ............................................$ 12.44 B
12 519-6400 ................ Upper Body .................................................................$ 85.58 B
13 819-6945 ................ Screw #12 x 1¼” PFH.................................................$ 0.96 B
14 519-9530 ................Mounting Plate, Standard ...........................................$ 24.40 B
14a 519-9550 ................Mounting Plate, Wide Mouth - White ..........................$ 35.20 B
14a 519-9557 ................Mounting Plate, Wide Mouth - Grey............................$ 36.96 B
15 711-9510 ................ Gasket, Standard ........................................................$ 17.34 B
15a 711-9520 ................ Gasket, Wide Mouth ...................................................$ 29.64 B
16 713-9520 ................ Spacer (3 Required)....................................................$ 15.50 B
17 550-9650 ................Weir Door Assembly....................................................$ 26.62 B
18 519-6350 ................Weir Door Hinge..........................................................$ 22.82 B
19 519-6470 ................ Diverter Plate ..............................................................$ 6.28 B
20 819-4350 ................ Screw 8 x ⅝” ...............................................................$ 0.50 B
21 715-9910 ................ Plug, 2” NPT................................................................$ 3.12 B
22 519-6410 ................ Lower Body 2½” Spigot x 2 Slip” S x 2” NPT ..............$ 113.02 B
1
3
4
6
7
8
9
13
10 11
12
16
14
15
2
5
13
16
15
164
17
18
14A
15A
1
2
7
8
9
10
11
12
20
19
21
22
3
4
5
6
