POOL PARTS MISCELLANEOUS
HYDROTECH BROMINATOR
SKU Number Description List Price Code
1 HT-NP25471 ........... Air Vent Nipple ............................................................$ 14.04 B
2 HT-NP25475 ........... O-Ring for Lexan Lid...................................................$ 12.12 B
3 HT-NP25476 ........... Clear Lexan Lid...........................................................$ 57.36 B
4 HT-NP25477 ........... Lid Retaining Bar ........................................................$ 22.96 B
5 HT-NP25478 ........... Calibrated Outlet Valve ...............................................$ 109.78 B
6 HT-NP25479 ........... Inlet Ball Valve.............................................................$ 100.86 B
7 HT-NP25480 ........... Calibrated Slot Ball Valve............................................$ 172.42 B
8 HT-NP25481 ...........¼” Hand Knob.............................................................$ 18.16 B
9 HT-NP25482 ........... Air Vent Line Assembly ...............................................$ 41.86 B
10 HT-NP25483 ........... Drain Plug ...................................................................$ 11.60 B
11 HT-NP25484 ........... Buna-A Gasket............................................................$ 4.56 B
12 HT-NP25485 ........... 2½” Saddle Clamp ......................................................$ 16.20 B
13 HT-NP25486 ........... Air Vent Tubing............................................................$ 12.78 B
HT-NP25491 ...........¾” Coupling.................................................................$ 5.08 B
HT-NP25492 ........... Saddle Clamp Nipple ..................................................$ 7.30 B
HT-NP25496 ........... Clear Flex Tubing........................................................$ 27.34 B
HT-NP25504 ........... O-Ring for Lid..............................................................$ 20.38 B
RAINBOW INLINE CHLORINATOR - MODEL 320
SKU Number Description List Price Code
1 R172008W ............. 3” Threaded Cap.........................................................$ 18.48 B
2 R172009 ................. O-Ring, Cap ................................................................$ 6.96 B
3 R172134 .................½” MPT PVC Plug.......................................................$ 6.52 B
4 R172321 ................. Body Only ...................................................................$ 51.12 B
5 R172256 .................½” x Short MPT Nipple................................................$ 5.92 B
6 R01052 ................... Lock Screw .................................................................$ 1.58 B
7 R172086 ................. Control Valve...............................................................$ 53.34 B
8 R172272 .................½” NPT x Tube 90° Ell with Nut ..................................$ 7.86 B
9 R172248 ................. Check Valve ................................................................$ 10.02 B
10 R172319 ................. Bottom O-Ring ............................................................$ 1.58 B
11 R172255 ................. Screen.........................................................................$ 5.92 B
12 R172317 ................. Diverter Tee 1½” NPT X 2”Slip....................................$ 27.54 B
13 R172091 ................. Short Feeder Tube ......................................................$ 5.92 B
14 R171097 ................. Tube Support Spring...................................................$ 5.80 B
R172628 ................. Saddle Clamp .............................................................$ 29.76 B
R172060 ................. Control Valve ¼" - for Models 300, 302 ......................$ 29.30 B
3
5
1
4
7
2
5 or 7
1
2
3
11
10
13
14
9 7
6
5
12
8
8
10
3
4
8
2
9
13
6
12 11
6
8
MA CHLORINATOR
SKU Number Description List Price Code
MA-NP25312C. . ..... Quick Connect Kit .......................................................$ 137.34 B
1 MA-NP25324 .......... Flowmeter with Check Valve.......................................$ 220.78 B
2 MA-NP25332 .......... Flow Control Valve ......................................................$ 63.32 B
3 MA-NP25340 .......... Blue Lid with O-Ring ...................................................$ 63.32 B
4 MA-NP25344 .......... PVC Drain Valve .........................................................$ 121.88 B
5 MA-NP25350 .......... O-Ring.........................................................................$ 6.74 B
6 MA-NP25352 .......... Flow-thru Return Fitting ..............................................$ 15.94 B
7 MA-NP25354 .......... Half Union ...................................................................$ 13.82 B
8 MA-NP25362 .......... Inline Check Valve.......................................................$ 66.76 B
9 MA-NP25366 .......... Outlet Check Valve......................................................$ 66.76 B
