24
Refrigeration
Aspera Nomenclature
59-AB1
Dimensions MFG
Series
6 1/2" × 4"
Aspera Series A and E
Tecumseh Series AE
Necchi
Series A and M
Danfoss Series PW
Americold Series M
7" × 4 1/2"
Aspera Series T
8" × 4 13/16"
Tecumseh Series AT & CAT
Copeland Series J
Kelvinator Series AO
More holes can be drilled for other
replacement requirement.
Compressor Mounting Adapters
59-AB1
Part #
Description
59-AB1
This flat mount plate is made from 16 gauge galvanized
steel 8" square with 8 holes to fit the following
compressor series and mounting centres shown in table.
59-AB8
Part #
Description
59-AB8
Adapter Base Instructions
Aspera Model E To Replace Tecumseh Model At And
Kelvinator Model Ao.
This Aspera model E compressor should be
assembled with the four adapter mounting brackets
as shown in this sketch. This will duplicate the 7" x 7"
base mounting dimensions of the original.
Compressor Nomenclature
NB, NE, T & J Series Compressor Nomenclature
59 - NB E 1 058 Y
Refrigerant
Capacity
The fist digit
indicates the
number of zeros
to be added to
the 2 following
digits to get the
rated capacity
at 50Hz. (in the
indicated example
the capacity is 58
Kcal/h).
Compressor
Series
NB, NE T & J.
59
Product
Category
Efficiency Level
M
- 1st generation.
K
- 2nd generation.
T
- 3rd generation.
U
- 4th generation.
E
- New improved
standard
efficiency level
(replaces both old
standard and first
generation levels).
Application Code
1
- LBP-LST.
2
- LBP-HST.
3
- LBP-LST oil cooler.
4
- LBP-HST oil cooler.
5
- MBP or HBP-LST.
6
- MBP or HBP-HST.
7
- AC.
9
- MBP/ HBP-HST.
Refrigerant Type Code &
Possible design Alternatives
A,B,C,D
- R12 single phase.
E,F,G
- R22 single phase.
K,J,F
- R502 single phase.
M,N
- R12 three phase.
P,R
- R22 three phase.
S,T
- R502 three phase.
U
- R290 single phase.
V
- R290/ R600a single phase.
Y
- R600a single phase.
Z,ZH,H
- R134a single phase.
ZX
- R134a three phase.
GE,GF,GG
- R407C single phase.
GJ,GK
- R404A single phase.
GS
- R404A three phase.
GP
- R407C three phase.
Compressors
