Refrigeration
Hermetic Separators - 300 & 900 Series
Part #
R-12
R-22
R-502
R-134A
R-404A
R-507
R-717
+40
Tons
-10
Tons
+40
Tons
-40
Tons
+40
Tons
-40
Tons
+40
Tons
-10
Tons
+40
Tons
-40
Tons
+40
Tons
-40
Tons
+40
Tons
-20
Tons
58-320
1.53 0.54 2.47 0.45 2.42 0.41 1.58 0.49 2.42 0.37 2.60 0.41 2.77 0.72
58-321
1.53 .54 2.47 0.45 2.42 0.41 1.58 0.49 2.42 0.37 2.60 0.41 2.77 0.72
58-322
1.53 0.54 2.47 0.45 2.42 0.41 1.58 0.49 2.42 0.37 2.60 0.41 2.77 0.72
58-340
3.06 1.08 4.93 .089 4.83 0.82 3.15 0.98 4.84 0.74 5.19 0.82 5.54 1.44
58-341
3.06 1.08 4.93 0.89 4.83 0.82 3.15 0.98 4.84 0.74 5.19 0.82 5.54 1.44
58-342
3.06 1.08 4.93 0.89 4.83 0.82 3.15 0.98 4.84 0.74 5.19 0.82 5.54 1.44
58-900
2.06 0.72 3.32 0.60 6.25 0.55 2.12 0.66 3.25 0.50 3.49 0.55 3.72 0.97
58-900-1
20.6 0.72 3.32 0.60 3.25 0.55 2.12 0.66 3.25 0.50 3.49 0.55 3.72 0.97
58-901
3.83 1.35 6.17 1.12 6.04 1.02 3.94 1.23 6.05 0.93 6.50 1.03 6.92 1.80
58-902
5.51 1.94 8.87 1.61 8.69 1.47 5.67 1.77 8.70 1.34 9.35 1.48 9.96 2.59
58-903
7.67 2.69 12.34 2.24 12.08 2.05 7.88 2.46 12.10 1.86 13.01 2.06 13.84 3.60
58-904
13.79 4.85 22.21 4.02 21.75 3.68 14.18 4.43 21.76 3.34 23.39 3.70 24.91 6.48
58-905
20.98 7.37 33.37 6.12 33.07 5.60 21.56 6.74 33.09 5.08 35.57 5.63 37.88 9.85
58-922
5.51 1.94 8.87 1.61 8.69 1.47 5.67 1.77 8.70 1.34 9.35 1.48 9.96 2.59
58-923
7.67 2.69 12.34 2.24 12.08 2.05 7.88 2.46 12.10 1.86 13.01 2.06 13.84 3.60
58-922R
5.51 1.94 8.87 1.61 8.69 1.47 5.67 1.77 8.70 1.34 9.35 1.48 9.96 2.59
58-923R
7.67 2.69 12.34 2.24 12.08 2.05 7.88 2.46 12.10 1.86 13.01 2.06 13.84 3.60
58-924
13.79 4.85 22.21 4.02 21.75 3.68 14.18 4.43 21.76 3.34 23.39 3.70 27.91 6.48
58-925
20.98 7.37 33.37 6.12 33.07 5.60 21.56 6.74 33.09 5.08 35.57 5.63 37.88 9.85
58-924R
13.79 4.85 22.21 4.02 21.75 3.68 14.18 4.43 21.76 3.34 23.39 3.70 27.91 6.48
58-925R
20.98 7.37 33.37 6.12 33.07 5.60 21.56 6.74 33.09 5.08 35.57 5.63 37.88 9.85
58-926
35.90 12.61 57.80 10.47 56.60 9.59 36.91 11.53 56.63 8.70 60.88 9.64 64.83 16.86
58-927
48.94 17.19 78.79 14.27 77.15 13.07 50.30 15.72 77.20 11.86 82.99 13.13 88.36 22.98
58-926R
35.90 12.61 57.80 10.47 56.60 9.59 36.91 11.53 56.63 8.70 60.88 9.64 64.83 16.86
58-927R
48.94 17.19 78.79 14.27 77.15 13.07 50.30 15.72 77.20 11.86 82.99 13.13 88.36 22.98
58-928
81.77 28.72 131.65 23.84 128.91 21.84 84.04 26.27 128.99 19.81 138.67 21.95 147.64 38.40
58-928R
81.77 28.72 131.65 23.84 128.91 21.84 84.04 26.27 128.99 19.81 138.67 21.95 147.64 38.40
58-930
139.01 48.82 223.81 40.53 219.15 37.13 142.87 44.66 219.28 33.68 235.74 37.32 250.99 65.28
58-930R
139.01 48.82 223.81 40.53 219.15 37.13 142.87 44.66 219.28 33.68 235.74 37.32 250.99 65.28
Impingement Screen Separators - 500 & 600 Series
Part #
R-12
R-22
R-502
R-134A
R-404A
R-507
R-717
+40
Tons
-10
Tons
+40
Tons
-40
Tons
+40
Tons
-40
Tons
+40
Tons
-10
Tons
+40
Tons
-40
Tons
+40
Tons
-40
Tons
+40
Tons
-20
Tons
58-501
1.83 1.51 2.8 2.38 2.8 2.38 1.83 1.51 2.8 2.38 2.8 2.38 3.32 3.07
58-502
3.66 3.02 5.6 4.76 5.6 4.76 3.66 3.02 5.6 4.76 5.6 4.76 6.65 6.13
58-503
5.49 4.49 8.4 7.14 8.4 7.14 5.49 4.49 8.4 7.14 8.4 7.14 9.97 9.20
58-504
7.32 6.04 11.2 9.52 11.2 9.52 7.32 6.04 11.2 9.52 11.2 9.52 13.27 12.24
58-505
9.16 7.55 14.0 11.9 14.0 11.9 9.16 7.55 14.0 11.9 14.0 11.9 15.64 14.43
58-506
13.0 10.7 23.6 19.9 23.6 19.9 13.0 10.7 23.6 19.9 23.6 19.9 26.66 24.59
58-507
23.0 19.0 40.0 34.0 40.0 34.0 23.0 19.0 40.0 34.0 40.0 34.0 45.2 41.69
58-600
1.22 1.01 1.87 1.59 1.87 1.59 1.22 1.01 1.87 1.59 1.87 1.59 2.21 2.05
58-601
1.83 1.51 2.8 2.38 2.8 2.38 1.83 1.51 2.8 2.38 2.8 2.38 3.32 3.07
58-602
3.66 3.02 5.6 4.76 5.6 4.76 3.66 3.02 5.6 4.76 5.6 4.76 6.65 6.13
58-603
5.49 4.49 8.4 7.14 8.4 7.14 5.49 4.49 8.4 7.14 8.4 7.14 9.97 9.20
58-604
7.32 6.04 11.2 9.52 11.2 9.52 7.32 6.04 11.2 9.52 11.2 9.52 13.27 12.24
58-605
9.16 7.55 14.0 11.9 14.0 11.9 9.16 7.55 14.0 11.9 14.0 11.9 15.64 14.43
58-606
13.0 10.7 23.6 19.9 23.6 19.9 13.0 10.7 23.6 19.9 23.6 19.9 26.66 24.59
58-607
23.0 19.0 40.0 34.0 40.0 34.0 23.0 19.0 40.0 34.0 40.0 34.0 45.2 41.69
Oil Separators Sizing Chart
NOTE 4.
TONS = Capacity in evaporator (12,000 BTU/Hr/Ton), based on +100ºF Condenser Temperature, -0ºF Sub-Cooling, +10ºF Super heat.
NOTE 5.
Capacity in tons and pounds per minute based on 140°F superheated discharge gas and the refrigerant entering the expansion valve at 110°F condensing temperature.
Oil Separators
