12
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
3.3" Motors
3.3" Motors
1550 RPM-115, 208, 230 Volt
Part # Amps
Volts HP Rot
Shaft
Body
Features
Comment
Fig.
R215
0.22
230 1/115 C.C.W. 2.3"x5/16" 2.09
Triangular Brk.Front
Electric Unit Htrs.
1
R511
0.28
230 1/100 C.W.
2.0"x1/4" 2.10
C ring groove, 1350 RPM FPE, Electrohome SN8401
2
R261
0.33
115 1/170 C.W 1.7"x5/16" 2.09
Cord & plug
Reversomatic
3
R403
0.33
115 1/145 C.W.
1.5"x1/4" 2.75
On/off switch on mtr., 72"
cord & plug.
Enterprise Fdry., Newmac
4
R401
0.35
115 1/165 C.C.W.
1.5"x1/4" 2.09
Conduit sleeve
Enterprise Fdry.
2
R503
0.40
115 1/130 C.W.
2.4"x1/4" 2.09
Notched shaft
Nutone, Air King
2108375001
2
R210
0.40
230 1/50 C.C.W.
1.5"x1/4" 2.40
24" Leads
Caloritech
5
R506
0.43
115 1/240 C.W.
2.0"x1/4" 1.90
Cord & plug, 1400 RPM 2N870, Nutone 80725
2
R227
0.45
115 1/110 C.C.W 2.3"x1/4" 2.09
Cord & plug
Gen. Replacement
6
R228
0.45
115 1/110 C.W.
2.1"x1/4" 2.09
Cord & plug
Gen. Replacement
6
R502
0.50
115 1/100 C.C.W.
3.4"x1/4" 2.44
72"Cord & Plug
Electrohome
2
R217
0.50
240 1/35 C.W.
1.2"x1/4" 2.40
Electric heater, 1450
RPM
Chromalox
5
R212
0.55
230 1/30 C.C.W. 3.5"x5/16" 2.80
Triangular Brk.
Ball Bearing
Chromalox electric heater
1
R206
0.56
115 1/80 C.W.
1.4"x1/4" 2.09
Two speed plug.
Miami-Carey, Air King, B.D.
Waite
4
R512
0.62
115 1/75 C.W.
1.0"x1/4" 2.09
C ring groove
Electrohome 2N10201,
2N11601
2
R230
0.64
115 1/70 C.C.W.
1.3"x1/4" 2.30
2800 RPM
Coldstream
2
R260
0.65
115 1/80 C.W.
1.1"x5/16" 2.09
Cord & plug
Reversomatic
3
R265
0.65
115 1/75 C.W.
1.6"x5/16" 2.09
Cord & plug
Reversomatic
3
R500
0.66
115 1/70 C.C.W.
2.1"x1/4" 2.35
2 studs rear
Tweed Steel
3
R204
0.70
115 1/80 C.C.W.
1.1"x1/4" 2.10
Threaded shaft,
1100 RPM
Nutone, Leigh Metal
5
R231
0.70
115 1/70 C.W.
1.3"x1/4" 2.50
Two speed plug,
2800 RPM
Nutone
5
R232
0.70
115 1/70 C.C.W.
1.3"x1/4" 2.50
Two speed plug.
Nutone
5
R222
0.72
115 1/75 C.C.W.
2.3"x1/4" 2.09
Cord & plug
Nutone
3
R454
0.74
230 1/25 C.C.W. 2.5"x5/16" 4.25
Mechanical duty
Gen. Replacement
7
R224
0.75
115 1/50 C.C.W.
C.C.W.
2.20
Cord & plug, 1500 RPM Gen. Replacement
8
R223
0.75
115 1/50 C.C.W.
C.C.W.
2.20
2 Studs front
Sylvan Source
8
R225
0.75
115 1/50 C.W.
2.3"x1/4" 2.20
Cord & plug, 1500 RPM Gen. Replacement
8
3.3" Motors continued on next page.
Totally Enclosed - Single Shaft
Sleeve & Ball Bearing - Shaded Pole
Fig. 1
R212
R215
Fig. 2
R230
R401
R502
R503
R506
R511
R512
Fig. 3
R260
R261
R265
R222
R500
Fig. 4
R206
R403
Fig. 5
R204
R210
R217
R231
R232
Fig. 6
R227
R228
Fig. 7
R454
Fig. 8
R224
R225
R223
