9
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
3.3" Motors
3.3" Motors
1550 RPM-115, 208, 230 volts
Part # Amps
Volts H.P.
Rot.
Shaft
Body
Feature
Comment
Fig.
R302
0.20
230 1/100 C.W.
2.0"x1/4" 2.25
4 studs rear
Camco, FPE
1
R325
0.33
115 1/125 C.C.W.
2.3"x1/4" 2.09
16" leads shaft end
W.C.Woods
2
R410
0.35
115 1/130 C.W.
2.0"x5/16" 2.75
L.K.Fitting-int.fan
Enterprise Fdry.
3
R371
0.38
230 1/20
C.W.
2.6"x5/16" 4.00
PSC/Cap. inc., Plug,
Ball Bearing
Keeprite 501909,
501525
5
R337
0.40
115 1/200 C.C.W.
1.5"x1/4" 2.30
2 speed motor
Hunter 902538
4
R326
0.40
115 1/110 C.W.
1.4"x1/4" 2.09
U Brk. 35" leads
Blanchard E1001,2,3 6
R311
0.47
115 1/100 C.W.
1.2"x5/16" 2.09
Hex Hubs, cord & plug
Nutone 81176,
23405
2
R320
0.47
115 1/100 C.W.
1.3"x1/4" 2.10
18" leads
Moyer & Diebel
2
R91125
0.50
208/230 1/12
CW 2.63"x5/16" 3.66
PSC/Cap.Inc
9720A, D1125,
41125
5
R315
0.53
115 1/90 C.C.W.
1.2"x1/4" 2.09
Hex Hubs, cord & plug
Nutone 82598,
82599, 65070
2
R317
0.60
115 1/65 C.C.W.
1.6"x1/4" 2.30
Hex hubs
Nutone 65072
2
R306
0.65
115 1/60
C.W.
1.2"x1/4" 2.92
Internal Fan / oilers
Coleman
3
R309
0.68
115 1/70
C.W.
2.4"x1/4" 2.00
12.5" leads
Gen. Replacement
2
R90015
0.70
115 1/70
CW 2.24"x1/4" 2.14
4 Studs front & rear
15, D121, 40121,
3M539
4
R90014
0.70
115 1/70 CCW 2.24"x1/4" 2.14
4 Studs front & rear
14, D120, 40120,
3M538
4
R308
0.70
115 1/70 C.C.W.
2.3"x1/4" 2.00
12.5" leads
Gen. Replacement
2
R370
0.75
115 1/20
C.W.
2.8"x5/16" 4.00
Cap.inc.Plug,
Ball Bearing
Keeprite 501895,
505124
5
R322
0.80
115 1/60
C.W.
1.3"x1/4" 2.00
Cord & plug
Broan 30080111,
112
3
R480
0.80
208/230 1/30 C.C.W.
2.4"x3/8" 4.00
4 Lugs Front and Back Chromalox/Westcan 7
R130
0.80
230 1/25
C.W.
1.5"x5/16" 2.72
Single U Brk, 35" leads
Blanchard0.
6
R395
0.81
208/230 1/20 C.W.
2.5"x5/16" 2.75
Cord & plug
Larkin 2531195
2
R90575
0.89
230 1/20
CW 2.48"x5/16" 2.75
2 Pin plug
575, D1103, 41195,
8
R304
0.89
115 1/40
C.W.
1.5"x1/4" 2.50
LK fitting.
Nutone
2
3.3" Motors continued on next page.
Fig. 5
R370
R371
R91125
Fig. 7
R480
Fig.8
R90575
Open Construction - Single Shaft
Sleeve & Ball Bearing - Shaded Pole & P.S.C.
Fig. 3
R306
R322
R410
Fig. 6
R130
R326
Fig. 4
R337
R90015
R90014
Fig. 1
R302
R304
R308
R309
R311
R315
R317
R320
R325
R395
Fig. 2
