7
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
Evaporator / Humidifier Motors
Evaporator Fan
/ Humidifier Motors
Part # HP Volts RPM Amps Rot Stack Shaft
Features
Comment
GEFM-1
1/350
115 2600 0.30 C.W. 0.50 1.5"x1/8"
2 or 3 point mounting
902065, WR60M103, WR60M113,
WR60X104,108, 203, 5023
UEFM-1
1/500
115 2600 0.22 C.C.W. 0.38 1.5"x1/8"
Two C-ring grooves on shaft,
7" cord c/w bare wire leads, c/w
fan blade
901293,292,241,
401767-101, WR60M111, 115,
1202159, 6494
WIFM-1
1/250
115 3000 0.40 C.C.W. 0.38 1.5"x1/8"
One C-ring groove on shaft,
7" cord c/w bare wire leads,
Bracket mount c/w all hardware
WR60M109,902440
446,C289446,C38791,20141846,2
0144334
Part # Watts Volts RPM Amps
Features
Comment
71-2800
4
24
1
0.83
Gen. Replacement, Includes 3 shaft
adapters
35,105,37,76,240,447,465,801,45S,90S,MD
035,60
71-2897
4
24
1
0.83
C/W mounting plates and 2 shaft
adapters
Autoflow 97, Lennox WD2-2-0
Single Speed - CW Rotation
Part # Amps Volts RPM Body Dia
Features
Comments
Fig
R6207
0.29
115 1550 2.10" 3.3"
With 2" Shaft Extension Habco, C020106, C020114
1
R6287
0.47
115 1550 3.00" 3.3"
10" Leads
Habco, C020287
1
R4119
0.60
115 1550 3.50" 3.9"
Two Pin Plug, Thr. Shaft
Scotsman 15W
2
R6203
0.60
115 1550 3.50" 3.9"
Two Pin Plug
Cornelius 15W, QBD
2
R6208
0.60
115 1550 3.40" 3.9"
10" Leads
Habco C020942, 15W
2
R5713
0.60
115 1550 3.50" 3.9"
Cord & Plug
15W,
CCW
2
R6209
0.60
115 1550 3.40" 3.9"
10" Leads
Habco C020943, 15W
2
R4110
0.80
115 1550 4.00" 3.9"
Two Pin Plug
Whirlpool, Frigidaire 23W
3
R6204
1.10
115 1550 3.50" 3.9"
Two Pin Plug
Cornelius 25W, QBD
2
R6205
1.10
115 1550 3.50" 3.9"
Two Pin Plug, Drive Pin Cornelius 25W, QBD
2
R6206
1.70
115 1550 3.50" 3.9"
1.125" Flat on Shaft
Cornelius 50W, QBD
2
Evaporator Fan Motors
Sleeve Bearing - Shaded Pole
Humidifier Motors
Agitator Motors
Sleeve Bearing - Shaded Pole
GEFM-1
UEFM-1
WIFM-1
71-2800
71-2897
Features
• Complete with hardware
• Use original fan blade
• Identical 2 or 3 point
mounting
Features
• Complete with fan blade
(93-40421)
• Use original hardware &
bracket
• Break off shaft for proper
length
Features
• Identical 2-point Westinghouse Mount or
Whirpool-Inglis bracket mount
• Complete with hardware and a fan hub.
• Use original fan blade
• Break off shaft for proper length.
Complete with
applicable drive coupling
Fig.1
Fig.2
Fig.3
