Motors
3.3" Motors
3.3" Motors
Open - 3000 RPM - Single / Double Shaft
Totally Enclosed - 3000 RPM - Single / Double Shaft
Sleeve & Ball Bearing - Shaded Pole & P.S.C. - 115 Volts
Sleeve & Ball Bearing - Shaded Pole & P.S.C. - 115 Volts
Single Shaft
Part #
Amps
HP
Rot
Shaft
Body
Features
Comment
Fig.
R90402
0.75
1/60
CCW 1.73"x1/4"
2.36
4 studs front & rear
D402, 40402
1
R90616
0.75
1/70
CW 0.96"x1/4"
2.28
Cord & plug
82500
1
R214
0.76
1/50
C.W.
1.5"x1/4"
2.80
2700 RPM
Nutone
2
R233
0.84
1/45 C.C.W.
1.8"x1/4"
2.50
2 Speed Plug
Nutone
4
R200
1.00
1/50 C.C.W.
1.2"x1/4"
2.60
2 Speed Plug
Miami-Carey
3
Double Shaft
Part # Amps.
H.P.
Rotation
Shaft
Body
Feature
Comment
Fig.
R412
0.55
1/75 C.C.W. 2.3"x1/4"x2.3" 2.40
22" cord & plug
Gen. Replacement
1
R425
1.00
1/40 C.W.
2.5"x1/4"x2.5" 2.60
4 studs front & back, two
speed
Gen. Replacement
1
Fig. 4
R233
Fig. 1
R412
R425
Fig. 2
R214
Fig. 1
R90402
R90616
Fig. 3
R200
Single Shaft
Part # Amps.
H.P.
Rotation
Shaft
Body
Feature
Comment
Fig.
R305
0.85
1/60
C.W.
1.5"x1/4" 2.30
Cord & plug, 2800 RPM
Nutone
1
R307
1.10
1/30 C.C.W.
1.3"x1/4" 3.30
Stud mounting
Keeprite
2
R312
1.20
1/12 C.C.W.
4.0"x5/16" 4.63
P.S.C (4/370), Internal Fan, Ball
Bearing, 3250 RPM
Engineered Air
101322
3
R334
2.30
1/15 C.C.W.
1.5"x1/4" 4.25
Internal Fan
Torin/Clare
4
Double Shaft
Part #
Amps.
H.P.
Rotation
Shaft
Body
Feature
Comment
Fig.
R413
0.95
1/35 C.C.W.
2.3x"x1/4"x2.5" 3.00
Int.Fan, cord & plug Gen. Replacement
1
R445
1.10
1/35 C.W.
1.5x"x1/4"x1.5" 2.80
75" cord & plug
Gen. Replacement
1
Fig. 1
R305
Fig. 2
R307
Fig. 3
R312
Fig. 4
R334
Fig. 1
R413
R445
