Butt’s Pumps and Motors - page 1541

50
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
Specialty Motors
Specialty Motors
Air Compressor Motors
Single Phase - Reversible - Ball Bearing - Drip Proof - Rigid Base - 1.0 SF - Manual Protection
Part # HP Amps Volts Spd/RPM Frame Body Shaft
Comments
S1400
3/4
12.5 115/230 1/3450 56 8.60 1.9"×5/8"K
-
S1402
1
15.0 115/230 1/3450 56 9.10 1.9"×5/8"K
-
S1404
1 1/2
15.0 115/230 1/3450 56 9.10 1.9"×5/8"K
DUAL CAPACITOR
S1406
2
24.0 115/230 1/3450 56
10.10 1.9"×5/8"K
-
S1408
3
15.0 208/230 1/3450 56 11.10 1.9"×5/8"K
DUAL CAPACITOR
S1410
5
22.0 208/230 1/3450 56HZ 11.12 2.3"×7/8"
DUAL CAPACITOR
Split Phase - Sleeve Bearing - CCW - Drip Proof - Resilient Base - 1.0 SF - Auto Protection
Part # HP Amps Volts Spd/RPM Frame Body
Shaft
Comments
R2024
1/4
5.8 115 1/1725 48Y 7.80 0.531"×1/2"
-
R2025
1/4
4.0 115/230 1/1725 48Y 8.10 0.531"×1/2"
50/60 HZ
R2034
1/3
6.2 115 1/1725 48Y 8.10 0.531"×1/2"
-
R2035
1/3
4.6 115/230 1/1725 48Y 8.10 0.531"×1/2"
50/60 HZ
R2054
1/2
6.8 115/230 1/1725 48Y 8.10 0.531"×1/2"
50/60 HZ
Split Phase - Single Phase - Ball Bearings - Drip Proof - Reversible - NEMA Service Factor
Part # HP Amps Volts Spd/RPM Frame
Shaft
Comments
S3800
1/6
3.3 115 1/1140 56CZ 2.1"×5/8"
CLASS A INSULATION
S3810
1/4
5.0 115 1/1140 56CZ 2.1"×5/8"
CLASS A INSULATION
Carbonator Pump Motors
Commercial & Industrial Fan & Blower Exhaust Ventilators Motors
Poultry / Barn Fans
Part # HP Amps Volts RPM Body Shaft
Comment
S9030
1/4
3.50 115 1/1725 7.60 2.9"x1/2"
MARATHON X903C/W 5/8"K
ADAPTER
S9040
1/3
4.50 115 1/1725 7.50 2.9"x1/2"
MARATHON X904C/W 5/8"K
ADAPTER
S9000
1/2
6.60 115/230 1/1725 7.50 1.6"x1/2"K
AGRICULTURE FAN APPLICATIONS
C/W 5/8" ADAPTER
Split Phase - Single Phase - Ball Bearings - Drip Proof - Reversible - NEMA Service Factor
