AC ADJUSTABLE SPEED DRIVES
INPUT LINE REACTORS
Catalogue Watts Dimensions (Inches)
HP Number Amps Loss Height x Width x Depth Weight
0.5 KDRA6L 1.1 5.6 4.00 x 4.18 x 3.75 4
0.75 KDRA7L 1.6 10 4.00 x 4.18 x 3.75 4
1 KDRA8L 2.1 10.4 4.00 x 4.18 x 3.75 4
1.5 KDRA9L 3 17 4.00 x 4.18 x 3.75 4
2 KDRA1L 3.4 19 4.00 x 4.18 x 3.75 4
3 KDRA2L 4.8 23 4.00 x 4.18 x 3.75 4
5 KDRA3L 7.6 49 4.00 x 4.18 x 3.75 4
7.5 KDRA4L 11 40 4.00 x 4.18 x 3.75 4
10 KDRA5L 14 64 4.00 x 4.18 x 3.75 5
15 KDRB2L 21 65 5.00 x 6.00 x 4.00 8
20 KDRB1L 27 79 5.00 x 6.00 x 4.00 8
25 KDRD1L 34 96 5.75 x 7.20 x 4.25 10
30 KDRD2L 40 105 5.75 x 7.20 x 4.25 10
40 KDRC1L 52 114 5.75 x 7.20 x 5.00 15
50 KDRF2L 65 114 7.00 x 9.00 x 6.00 25
60 KDRF4L 77 169 7.00 x 9.00 x 6.00 25
75 KDRF3L 96 193 7.00 x 9.00 x 6.00 30
100 KDRH3L 124 225 7.00 x 9.00 x 7.00 40
125 KDRH2L 156 254 9.00 x 11.00 x 7.00 40
150 KDRH1L 180 299 9.00 x 11.00 x 7.00 40
200 KDRG3L 240 280 9.00 x 11.00 x 8.00 65
250 KDRG1L 302 337 9.00 x 11.00 x 8.00 65
300 KDRG2L 361 381 9.00 x 11.00 x 8.00 65
350 KDRJ2L 414 465 9.00 x 11.00 x 9.00 70
{nä6ÊUÊ "7Ê­<®Ê * Ê
Low “Z” units can be used in any application where traditionally either a
1.5% or 3% impedance reactor would be applied.
Catalogue Watts Dimensions (Inches)
HP Number Amps Loss Height x Width x Depth Weight
0.5 KDRA6H 1.1 9 4.00 x 4.18 x 3.75 4
0.75 KDRA7H 1.6 15 4.00 x 4.18 x 3.75 4
1 KDRA8H 2.1 12 4.00 x 4.18 x 3.75 4
1.5 KDRA9H 3 23 4.00 x 4.18 x 3.75 4
2 KDRA1H 3.4 33 4.00 x 4.18 x 3.75 4
3 KDRA2H 4.8 38 4.00 x 4.18 x 3.75 4
5 KDRA3H 7.6 80 4.00 x 4.18 x 3.75 4
7.5 KDRA4H 11 77 4.00 x 4.18 x 3.75 5
10 KDRA5H 14 111 4.00 x 4.18 x 3.75 5
15 KDRB2H 21 133 5.00 x 6.00 x 4.00 7
20 KDRC3H 27 108 5.75 x 7.20 x 5.00 15
25 KDRC1H 34 112 5.75 x 7.20 x 5.00 15
30 KDRE2H 40 141 5.75 x 7.20 x 5.00 16
40 KDRF4H 52 169 7.00 x 9.00 x 6.00 25
50 KDRF1H 65 191 7.00 x 9.00 x 6.00 25
60 KDRF2H 77 226 7.00 x 9.00 x 6.00 25
75 KDRH2H 96 212 9.00 x 11.00 x 7.00 45
100 KDRI2H 124 362 9.00 x 11.00 x 7.00 50
125 KDRG3H 156 274 9.00 x 11.00 x 8.00 55
150 KDRG1H 180 359 9.00 x 11.00 x 8.00 55
200 KDRJ1H 240 420 9.00 x 11.00 x 9.00 70
250 KDRL1H 302 548 11.38 x 14.50 x 9.50 110
300 KDRL2H 361 786 11.38 x 14.50 x 9.31 95
350 KDRL3H 414 750 11.38 x 14.50 x 9.31 100
{nä6ÊUÊ Ê­<®Ê *
High “Z” units can be used in any application where traditionally a 5%
impedance reactor would be applied.
Catalogue Watts Dimensions (Inches)
HP Number Amps Loss Height x Width x Depth Weight
0.5 KDRA55L 0.9 6 4.00 x 4.18 x 3.75 4
0.75 KDRA56L 1.3 9.3 4.00 x 4.18 x 3.75 4
1 KDRA50L 1.7 12 4.00 x 4.18 x 3.75 4
1.5 KDRA51L 2.4 19 4.00 x 4.18 x 3.75 4
2 KDRA46L 2.7 22 4.00 x 4.18 x 3.75 4
3 KDRA52L 3.9 23.3 4.00 x 4.18 x 3.75 4
5 KDRA47L 6.1 34.7 4.00 x 4.18 x 3.75 4
7.5 KDRA48L 9 42.9 4.00 x 4.18 x 3.75 4
10 KDRA49L 11 43.8 4.00 x 4.18 x 3.75 5
15 KDRB45L 17 66.2 5.00 x 6.00 x 4.00 8
20 KDRB44L 22 71.2 5.00 x 6.00 x 4.00 8
25 KDRB43L 27 76.7 5.00 x 6.00 x 4.00 8
30 KDRD42L 32 106 5.75 x 7.20 x 4.25 12
40 KDRC43L 41 109 5.75 x 7.20 x 5.00 15
50 KDRC44L 52 123 5.75 x 7.20 x 5.00 15
60 KDRF46L 62 181 7.00 x 9.00 x 6.00 30
75 KDRF47L 77 194 7.00 x 9.00 x 6.00 30
100 KDRF45L 99 194 7.00 x 9.00 x 6.00 30
125 KDRH43L 125 261 9.00 x 11.00 x 7.00 45
150 KDRH44L 144 253 9.00 x 11.00 x 7.00 45
200 KDRI42L 192 342 9.00 x 11.00 x 7.00 50
250 KDRG47L 242 394 9.00 x 11.00 x 8.00 65
300 KDRG45L 289 374 9.00 x 11.00 x 8.00 65
350 KDRJ45L 336 474 9.00 x 11.00 x 9.00 70
xÇx‡Èää6ÊUÊ "7Ê­<®Ê *
Low “Z” units can be used in any application where traditionally either a
1.5% or 3% impedance reactor would be applied.
Catalogue Watts Dimensions (Inches)
HP Number Amps Loss Height x Width x Depth Weight
0.5 KDRA55H 0.9 9 4.00 x 4.18 x 3.75 4
0.75 KDRA52H 1.3 13 4.00 x 4.18 x 3.75 4
1 KDRA50H 1.7 17 4.00 x 4.18 x 3.75 4
1.5 KDRA51H 2.4 26 4.00 x 4.18 x 3.75 4
2 KDRA43H 2.7 24 4.00 x 4.18 x 3.75 4
3 KDRA44H 3.9 35 4.00 x 4.18 x 3.75 4
5 KDRA45H 6.1 48 4.00 x 4.18 x 3.75 4
7.5 KDRB42H 9 61 5.00 x 6.00 x 4.00 8
10 KDRB43H 11 71 5.00 x 6.00 x 4.00 8
15 KDRB44H 17 73 5.00 x 6.00 x 4.00 8
20 KDRD41H 22 106 5.75 x 7.20 x 4.25 12
25 KDRC43H 27 107 5.75 x 7.20 x 5.00 15
30 KDRE42H 32 140 5.75 x 7.20 x 5.00 16
40 KDRF44H 41 172 7.00 x 9.00 x 6.00 30
50 KDRF45H 52 166 7.00 x 9.00 x 6.00 30
60 KDRH43H 62 205 9.00 x 11.00 x 6.00 45
75 KDRH42H 77 251 9.00 x 11.00 x 6.00 45
100 KDRI41H 99 268 9.00 x 11.00 x 7.00 50
125 KDRG44H 125 381 9.00 x 11.00 x 7.50 65
150 KDRG45H 144 406 9.00 x 11.00 x 8.00 65
200 KDRJ41H 192 466 9.00 x 11.00 x 9.00 70
250 KDRL46H 242 472 11.38 x 15.00 x 11.00 110
300 KDRL47H 289 490 11.38 x 15.00 x 11.00 110
350 KDRL48H 336 539 11.38 x 15.00 x 11.00 110
xÇx‡Èää6ÊUÊ Ê­<®Ê * Ê
High “Z” units can be used in any application where traditionally a 5%
impedance reactor would be applied.
