Specifications are subject to change without notice
Drives
CHASSIS MOUNT
HP Range
Output
Output
Catalogue
App.
115 VAC
230 VAC
Voltage DC
Amps
Number
Wgt.
1/20 to 1/4
—
0-130
2
XP02-115AC
1.77
1/4 to 1/2
—
0-130
5
XP05-115AC
2.36
1/2 to 1
—
0-130
10^
XP10-115AC
2.88
Heat Sink^
223-0159
1
^ Requires #223-0159 above 5 amps.
HP Range
Output
Output
Catalogue
App.
115 VAC
230 VAC
Voltage DC
Amps
Number
Wgt.
1/40 to 1/8 1/40 to 1/4
-
3
M1740008
5
1/20 to 1/3 1/8 to 1/2 0-130/0-240
3
C4XL3025
5
1/4 to 1
1/4 to 2
0-130/0-240 10
C4XL3200A
5
CHASSIS MOUNT
HP Range
Output
Output
Catalogue
App.
115 VAC 230 VAC
Voltage DC
Amps
Number
Wgt.
1/20 to 1/4 1/10 to 1/2 0-130/0-240
2
MMXL02-D240AC
2.5
1/20 to 1/4 1/8 to 1/3 0-130/0-240
3
XL3025A
1.8
1/8 to 1/2
1/4 to 3/4 0-130/0-240
5
XL3050A
2.0
1/4 to 1/2
1/2 to 1
0-130/0-240
5
MMXL05-D240AC
3.2
1/4 to 1
1/2 to 2
0-130/0-240 10*
XL3200A
2.5
1/2 to 1
1 to 2
0-130/0-240 10^
MMXL10-D240AC
3.9
1/4 to 1-1/2
1/2 to 3
0-130/0-240
15
XL3300A
†
2.5
Isolation option#
“-PCM”
Heat Sink*
223-0271
1
Heat Sink^
223-0159
1
^ Requires #223-0159 above 5 amps.
* Requires #223-0271 above 5 amps.
!DD THE DESIGNATION h 0#-v TO THE END OF AN --8, CONTROL
for pricing add the list of the -PCM to the list of the control.
†
This item provides 0-120% jog speed (% of rated)
161
PWM CONTROLS
XL Series
XL Series
filtered pulse-width-modulated
(PWM) variable-speed DC drives provide
exceptional performance. They output nearly
pure DC power to brush-type motors ranging
from 1/20 to 3 HP. Drives accept 120 or 240
VAC input to output 0 to 130 or 240 VDC,
respectively, resulting in higher speeds from
standard 90 or 180 VDC SCR duty motors.
This innovative technology lets users operate
many low voltage motors with only minor
calibration adjustments.
MOSFET power devices switch at 22 kHz,
which is above the audible range, to provide
fast circuit response and a constant 1.05 form
factor over the entire 100:1 speed range.
(IGHLY EFFICIENT 8, DRIVES PROVIDE COOL QUIET
motor operation with extended brush life and
low maintenance. For convenience, the drives
have a cage-clamp terminal block to make wiring easy.
The
MMXL Series
is a full-featured PWM drive reduced down to the standard
-- FOOTPRINT
v X v )T HAS ALL THE FEATURES OF THE 8, 3ERIES WITH
added optional isolation to the speed circuit and the inhibit circuit in the
“-PCM” model. This means that the speed can be controlled with any 0-5
VDC signal and many drives can be inhibited with a single contact closure.
The auto ranging power supply allows the user to apply 120 or 240 VAC
WITHOUT ADJUSTING ANY SWITCHES 4HE FULL FEATURED --8, IS ONE OF THE SMALLEST
PWM drives on the market today!
XP Series
Specifically designed for the original
equipment manufacturer (OEM), XP
Series DC motor speed drives provide high
performance at a low cost. These drives
ARE WELL SUITED FOR 8, DRIVE CANDIDATES WHO
DO NOT NEED FULL 8, FEATURES 80 DRIVES ARE
versatile. They can accept any AC voltage
between 70 and 130 VAC. XP drives contain
a unipolar power supply, which enables the
drive to accept DC (100-160 VDC), unlike typical transformer coupled drives.
Depending on your application needs, these drives will provide speed control
for motors ranging from 1/20 through 1 HP.
Features:
s 0ULSE 7IDTH -ODULATION
1.05 form factor at any speed in a 100:1 speed range.
This means a decrease in motor temperature and brush maintenance. Allows for
higher output voltage, thus faster motor speed.
s
K(Z 3WITCHING &REQUENCY
Beyond the audible range providing faster
circuit response and low form factor.
s
On-Board Diagnostics:
! GREEN ,%$ INDICATES A POWERED DRIVE A RED ,%$
indicates current limit.
s !DJUSTABLE 4RIMMER 0OTS
Accel. & decel. (0.5 - 6 seconds), IR Comp, current
limit, min. & max. speed trimmer pots for application-specific calibration.
s )SOLATION /PTION
Isolated input circuit for speed and inhibit. Any 0 - 5 VDC will
control speed and a single contact closure can inhibit many drives (“-PCM”).
s -- &OOTPRINT
One of the smallest full-featured PWM drives on the market
(4.30” x 3.64”).
Ê£ÊEÊ Ê{8ÊUÊ "-
4HE # 8, SERIES ARE DUAL VOLTAGE HIGH PERFORMANCE 07- .%-! 8 ENCLOSED DRIVES
for 1/20-2hp DC brushed motors. PWM technology allows the drives to yield a constant
1.05 form factor over the 100:1 speed range resulting in smooth, quiet, cool and low
maintenance motor operation. Enclosure protects the drive from accidental contact,
liquids falling objects and corrosive agents.
DC ADJUSTABLE SPEED DRIVES
PULSE-WIDTH-MODULATED CONTROLS
