MOTOR PROTECTION FILTERS
V1000 KLC SERIES
The V1000 is guaranteed by TCI to limit motor terminal voltage to 150% of bus voltage (peak input voltage)
when applied to the output of a VFD and ahead of a motor connected with up to 2000ft leads depending
on carrier frequency and lead type and following the manufacturer’s guidelines. The V1K must be sized
at no more than 110% of the drive output current rating. Additional restrictions apply for multiple motor
applications, consult factory. The V1K must be sized to have regular line current loading of no less than
25% of its current rating. If the load has a potential for overhauling the drive must be equipped with braking
resistors or other features limiting bus voltage to no more than the level of the peak line voltage. The V1K
must be wired no more than 12 feet from the drive.
The addition of a TCI V1000 filter will
help reduce motor heating, motor
noise, and motor vibration by reducing
the current harmonics in a drive
system.
Peak Voltages on a 460V system can
reach 1200 to 1600 V, causing rapid
breakdown of motor insulation, leading
to motor failure. On 575 V systems, the
peak voltages can easily reach 2100 V. If
this is left uncontrolled, insulation failure
may occur. The same peak voltages that
damage the motor can also damage the
cable. Since the V1000 filters are designed
to be placed at the output of the drive,
these units will also protect the cable runs.
Electrical Features:
High Performance
s ,IMITS 0EAK 6OLTAGE
s )NCREASES 6OLTAGE 2ISE 4IME
Reduce Filter Size
s 3MALLER -ECHANICAL ,AYOUT
Specific Applications can reach 3000 feet
(individual results may vary)
Single Motor or Multiple Motor
Efficiency is greater than 98%
5, AND #5, ,ISTED
Filtering increases Motor Life
The V1000 reduces common mode current
by at least 30%. The V1000 substantially
slows down the rate of change of the
PWM switching as seen by the load. The
slowing of the rate of change of the PWM
switching increases the capacitive coupling
impedance between bearings and bearing
races. The increase in capacitive coupling,
in turn, reduces the damaging Common
Mode Currents and increases motor
up-time. The V1000 reduces bearing,
pitting, and fluting.
The V1000 Motor Protecting Output Filters
have been designed to limit peak voltage
and increase voltage rise time. In specific
applications, the V1000 has performed
with cable runs of up to 3,000 feet.
Catalogue
Motor HP
Rated
Dim. (in.)
Weight
EX Model
Number
480V
600V
240V
Current
H” x W” x D”
(lbs)
Cat. Number
V1K2A00
0.75
1
-
2
9.00 x 5.50 x 7.25
8
V1K2A00EX
V1K3A00
1 - 1.5
2
0.5
3
9.00 x 5.50 x 7.25
8
V1K3A00EX
V1K4A00
2
3
0.75
4
9.00 x 5.50 x 7.25
8
V1K4A00EX
V1K6A00
3
-
1 - 1.5
6
9.00 x 5.50 x 7.25
8
V1K6A00EX
V1K8A00
5
5
2
8
9.00 x 5.50 x 8.25
8
V1K8A00EX
V1K12A00
7.5
10
3
12
9.00 x 5.50 x 8.25
8
V1K12A00EX
V1K16A00
10
-
5
16
9.00 x 5.50 x 8.25
12
V1K16A00EX
V1K18A00
10
15
-
18
9.00 x 5.50 x 8.25
12
V1K18A00EX
V1K21A00
15
-
-
21
9.00 x 5.50 x 8.25
12
V1K21A00EX
V1K25A00
15
20
7.5
25
9.00 x 5.50 x 8.25
12
V1K25A00EX
V1K27A00
20
25
-
27
9.00 x 5.50 x 8.25
14
V1K27A00EX
V1K35A00
25
30
10
35
12.00 x 8.00 x 9.00
17
V1K35A00EX
V1K45A00
30
40
15
45
12.00 x 8.00 x 9.00
17
V1K45A00EX
V1K55A00
40
50
20
55
12.00 x 8.00 x 9.00
23
V1K55A00EX
V1K80A00
50 - 60
75 25 - 30 80
12.00 x 8.00 x 9.00
23
V1K80A00EX
V1K110A00
75
100
40
110 12.00 x 8.00 x 10.25
40
V1K110A00EX
V1K130A00
100
125
50
130 8.50 x 11.75 x 9.50
55
V1K130A00EX
V1K160A00
125
150
60
160 8.50 x 11.75 x 10.50
60
V1K160A00EX
V1K200A00
150
200
75
200 8.50 x 11.75 x 9.25
60
V1K200A00EX
V1K250A00
200
250
100
250 8.50 x 11.75 x 9.25
65
V1K250A00EX
V1K305A00
250
300
-
305 8.75 x 11.75 x 12.25
80
V1K305A00EX
V1K362A00
300
350
150
362 8.75 x 11.75 x 12.00
80
V1K362A00EX
V1K420A00
350
450
-
420 10.00 x 11.75 x 13.75 95
V1K420A00EX
V1000 OPEN FILTER
Catalogue
Motor HP
Rated
Dim. (in.)
Weight
EX Model
Number
480V
600V
240V
Current
H” x W” x D”
(lbs)
Cat. Number
V1K2A01
0.75
1
-
2
9.00 x 5.50 x 10.00
11
V1K2A01EX
V1K3A01
1 - 1.5
2
0.5
3
9.00 x 5.50 x 10.00
11
V1K3A01EX
V1K4A01
2
3
0.75
4
9.00 x 5.50 x 10.00
11
V1K4A01EX
V1K6A01
3
-
1 - 1.5
6
9.00 x 5.50 x 10.00
11
V1K6A01EX
V1K8A01
5
5
2
8
9.00 x 5.50 x 10.00
11
V1K8A01EX
V1K12A01
7.5
10
3
12
9.00 x 5.50 x 10.00
11
V1K12A01EX
V1K16A01
10
-
5
16
9.00 x 5.50 x 10.00
15
V1K16A01EX
V1K18A01
10
15
-
18
9.00 x 5.50 x 10.00
15
V1K18A01EX
V1K21A01
15
-
-
21
9.00 x 5.50 x 10.00
15
V1K21A01EX
V1K25A01
15
20
7.5
25
9.00 x 5.50 x 10.00
15
V1K25A01EX
V1K27A01
20
25
-
27
9.00 x 5.50 x 10.00
15
V1K27A01EX
V1K35A01
25
30
10
35 12.00 x 8.00 x 11.50
23
V1K35A01EX
V1K45A01
30
40
15
45 12.00 x 8.00 x 11.50
23
V1K45A01EX
V1K55A01
40
50
20
55 12.00 x 8.00 x 11.50
23
V1K55A01EX
V1K80A01
50 - 60
75 25 - 30 80 12.00 x 8.00 x 11.50
29
V1K80A01EX
V1K110A01
75
100
40
110 16.50 x 18.00 x 15.00 68
V1K110A01EX
V1K130A01
100
125
50
130 16.50 x 18.00 x 15.00 83
V1K130A01EX
V1K160A01
125
150
60
160 16.50 x 18.00 x 15.00 83
V1K160A01EX
V1K200A01
150
200
75
200 16.50 x 18.00 x 15.00 93
V1K200A01EX
V1K250A01
200
250
100
250 16.50 x 18.00 x 15.00 93
V1K250A01EX
V1K305A01
250
300
-
305 16.50 x 18.00 x 30.00 117
V1K305A01EX
V1K362A01
300
350
150
362 16.50 x 18.00 x 30.00 117
V1K362A01EX
V1K420A01
350
450
-
420 16.50 x 18.00 x 30.00 132
V1K420A01EX
* Use the “EX” version of the filter under the following situations:
V1000 ENCLOSED FILTER
FLEXIBLE ARMORED THHN CABLE -
UNITS 35 AMPS AND BELOW
&REQUENCY
#ABLE ,ENGTH
(kHz)
100’ 101’-500’ 501’-1000’ >1000’
2
std.
std.
std.
4
std.
std.
std.
6
std.
std.
MtrGrd
8
std.
MtrGrd MtrGrd
FLEXIBLE ARMORED THHN CABLE -
UNITS 45 AMPS TO 420 AMPS
&REQUENCY
#ABLE ,ENGTH
(kHz)
100’ 101’-500’ 501’-1000’ >1000’
2
std.
std.
std.
4
std.
std.
std.
6
std.
std.
std.
8
std.
FLAT CABLE OR VFD CABLE -
UNITS 35 AMPS AND BELOW
&REQUENCY
#ABLE ,ENGTH
(kHz)
100’ 101’-500’ 501’-1000’ >1000’
2
std.
std.
std.
4
std.
std.
MtrGrd
6
std.
std.
MtrGrd MtrGrd
8
MtrGrd MtrGrd MtrGrd MtrGrd
FLEXIBLE ARMORED THHN CABLE -
UNITS 45 AMPS TO 420 AMPS
&REQUENCY
#ABLE ,ENGTH
(kHz)
100’ 101’-500’ 501’-1000’ >1000’
2
std.
std.
std.
4
std.
std.
MtrGrd
6
std.
MtrGrd MtrGrd
8
MtrGrd MtrGrd
MtrGrd MtrGrd
