170
Specifications are subject to change without notice
Controls
CONTACTORS
Auxiliary
“Single phase
“Three phase
Motor
Resistive
4YPE
CONTACTS
;(0= !
;(0= !
,OAD
,OAD
NO
NC
120V
240V
200-208V
240V
480V
600V
AC-3
AC-1
BG09 10 A
s
1
½ (9.8)
1½ (10)
2 (7.8)
3 (9.6)
5 (7.6)
5 (6.1)
9
20
BG12 01 A
s
1
½ (9.8)
1½ (10)
3 (11)
3 (9.6)
7½ (11)
10 (11)
12
20
BF09 10 A
s
1
¾ (13.8)
2 (12)
3 (11)
3 (9.6)
5 (7,6)
7 ½ (9)
9
25
BF09 01 A
s
1
¾ (13.8)
2 (12)
3 (11)
3 (9.6)
5 (7,6)
7 ½ (9)
9
25
BF12 10 A
s
1
1 (16)
2 (12)
5 (17.5)
5 (15.2)
7½ (11)
10 (11)
12
28
BF12 01 A
s
1
1 (16)
2 (12)
5 (17.5)
5 (15.2)
7½ (11)
10 (11)
12
28
BF18 10 A
s
1
1 (16)
3 (17)
5 (175)
5 (15.2)
10 (14)
15 (17)
18
32
BF18 01 A
s
1
1 (16)
3 (17)
5 (175)
5 (15.2)
10 (14)
15 (17)
18
32
BF25 10 A
s
1
2 (24)
3 (17)
7½ (25.3)
7½ (22)
15 (21)
15 (17)
25
32
BF25 01 A
s
1
2 (24)
3 (17)
7½ (25.3)
7½ (22)
15 (21)
15 (17)
25
32
BF26 00 A
s
-
-
2 (24)
5 (28)
7½ (25.3)
7½ (22)
15 (21)
20 (22)
26
45
BF32 00 A
s
-
-
3 (34)
7½ (40)
10 (32.2)
10 (28)
20 (27)
25 (27)
32
55
BF38 00 A
s
-
-
3 (34)
7½ (40)
10 (32.2)
15 (42)
30 (40)
30 (32)
38
55
BF50 00 A
s
-
-
5 (56)
10 (50)
10 (32.2)
15 (42)
30 (40)
40 (41)
50
90
11 BF65 00
s
-
-
-
-
20 (59.4)
25 (68)
50 (65)
60 (62)
65
110
11 BF80 00
s
-
-
-
-
25 (78.2)
30 (80)
60 (77)
75 (77)
80
125
11 BF95 00
s
-
-
-
-
30 (92)
30 (80)
60 (77)
75 (77)
95
125
11 BF110 00
s
-
-
30 (92)
40 (104)
75 (96)
100 (99)
110
125
11 B115 00
l
-
-
-
-
30 (92)
40 (104)
75 (96)
100 (99)
115
160
11 B145 00
l
-
-
-
-
50 (150)
50 (130))
100 (124)
125 (125)
145
250
11 B180 00
l
-
-
-
-
60 (177)
75 (192)
150 (180)
150 (144)
180
275
11 B250 00
l
-
-
-
-
75 (221)
100 248)
200 (240)
250 (242)
265
350
11 B310 00
l
-
-
-
-
100 285)
125 (312)
250 (302)
300 (289)
320
450
11 B400 00
l
-
-
-
-
125 (359)
150 (360)
350 (414)
400 (382)
420
550
INDUSTRIAL CONTROLS
#/.4!#4/23 s )%#
AC and DC versions of same size
Quick connect - snap on accessory mounting
Distinct contact status indication
Up to 4 auxiliary contacts can be mounted
Mechanical interlock only 5mm deep
,OW $# CONSUMPTION INTERFACE TYPE
Positively-guided contacts
BG SERIES
4 different frame sizes up to 75HP
Anti-shock magnetic core design
Straight through wiring
Wide coil operating range
Coil removable without disconnecting power wiring
Easy contact inspection and replacement
Specific version for power factor correction systems
Positively-guided contacts
BF SERIES
3 frame sizes offering 11 different contactors
Coil operates indifferently on AC or DC supply voltage
Coil with low in-rush and holding
Coil removable without disconnecting power wiring
Red indicator when contactor is energised
Unique right-angle magnet design - limits contact bounce
Safety feature prevents contactor making without arc
chute in place and locked in position
Simple horizontal and vertical interlocks
Positively-guided contacts
B SERIES
Part Number
BFX1002
2NC
BFX1011
1NO+1NC
BFX1020
2NO
BFX1004
4NC
BFX1013
1NO+3NC
BFX1022
2NO+2NC
BFX1031
3NO+1NC
BFX1040
4NO
FRONT MOUNT AUXILIARY
CONTACTS (UP TO BF110)
Part Number
BFX12 02
2NC
BFX12 11
1NO+1NC
BFX12 20
2NO
SIDE MOUNT AUXILIARY
CONTACTS (UP TO BF38)
Coil Digit
Voltage Range
02460
24V
12060
120V
23060
230
46060
440-480V
57560
575-600V
s
Coil Code for
contactors 6A to 110 A
Coil Digit
Voltage Range AC/DC
024
24V
110
110-125V
220
220-240V
460
440-480V
550
550-600V
l
Coil Code for contactors
115A to 400 A
