171
Specifications are subject to change without notice
Controls
INDUSTRIAL CONTROLS
OVERLOADS
Adjustment Range
Catalog
(A)
Number
0.1-0.16
RF38 0016
0.16-0.25
RF38 0025
0.25-0.4
RF38 0040
0.4-0.63
RF38 0063
0.63-1
RF38 0100
1.6-1.6
RF38 0160
1.6-2.5
RF38 0250
2.5-4
RF38 0400
4-6.5
RF38 0650
6.3-10
RF38 1000
9-14
RF38 1400
13-18
RF38 1800
17-23
RF38 2300
20-25
RF38 2500
24-32
RF38 3200
32-38
RF38 3800
THREE PHASE
Automatic /Manual
Direct Mount
For BF Series 9A TO 38 A
Adjustment Range
Catalog
(A)
Number
20-33
11RF95 3 33
28-42
11RF95 3 42
35-50
11RF95 3 50
46-65
11RF95 3 65
60-82
11RF95 3 82
70-95
11RF95 3 95
90-110
11RF95 3 110
THREE PHASE
Direct Mount/Manual Reset
For BF Series 50 TO 110 A
Catalog
For Overload
Number
RF …38
RFX3804
RF…95
11G270
8
8
Remove the links fixed on the RF..95 and
use those supplied with 11G270
Din Rail mount adapter
Adjustment Range
Catalog
(A)
Number
60-100
RF200 100
75-125
RF200 125
90-150
RF200 150
120-200
RF200 200
THREE PHASE
For B Series 60 TO 200 A
B115-B145-B180
Using G372 Links
B250-B310-B400
Using G373 Links
Adjustment Range
Catalog
(A)
Number
0.09-0.15
11 RF9 015
0.14-0.23
11RF9 023
0.2-0.33
11RF9 033
0.3-0.5
11RF9 05
0.45-0.75
11RF9 075
0.6-1
11RF9 1
0.9-1.5
11RF9 1V5
1.4-2.3
11RF9 2V3
2-3.3
11RF9 33
3-5
11RF9 5
4.5-7.5
11RF9 75
6-10
11RF9 10
9-15
11RF9 15
THREE PHASE
Direct Mount -Manual Reset
For Mini Contactors
Type BG06 ,09 ,12
