54
Refrigeration
Oil Separator - Accessible Coalescent
Part #
Maximum
Working
Pressure
Oil
Connector
Size
Diameter
Dimensions
Oil Change
Amount
Weight
"A"
"B"
"C" "D"
58-926
450 PSIG 1/4" SAE 6"
1 5/8" ODS 31" 34 3/4" 30 1/2" 34oz 1L 34lbs.
58-927
450 PSIG 1/4" SAE 6"
2 1/8" ODS 31" 34 3/4" 30 1/2" 34oz 1L 34lbs.
58-926R
450 PSIG 3/8" SAE 6"
1 5/8" ODS 33 7/8" 39 3/8" 16 5/8" 1.8gal 6.7L 41lbs.
58-927R
450 PSIG 3/8" SAE 6"
2 1/8" ODS 33 7/8" 39 3/8" 16 5/8" 1.8gal 6.7L 41lbs.
58-924
to
58-925
Series
58-924R
to
58-925R
Series
Oil Separator - Accessible Coalescent
Part #
Maximum
Working
Pressure
Oil
Connector
Size
Diameter
Dimensions
Oil Change
Amount
Weight
"A"
"B"
"C" "D"
58-928
450 PSIG 3/8" SAE 8 5/8" 2 5/8" ODS 33 5/8" 40 1/4" 12"
34oz 1L 150lbs.
58-928R
450 PSIG 3/8" SAE 8 5/8" 2 5/8" ODS 38 7/8" 45 1/2" 18" 3.5gal 13.25L 166lbs.
Oil Separator - Accessible Coalescent
Part #
Maximum
Working
Pressure
Oil
Connector
Size
Diameter
Dimensions
Oil Change
Amount
Weight
"A"
"B"
"C" "D"
58-930
450 PSIG 3/8" SAE 12 3/4" 3 1/8" ODS 35 3/4" 43 3/8" 13 3/4" 85oz 2.5L 300lbs.
58-930R
450 PSIG 3/8" SAE 12 3/4" 3 1/8" ODS 37 1/8" 44 3/4" 15 1/8" 5.7gal 21.25L 310lbs.
Oil Separators - Accessible Coalescent
58-928
Series
58-928R
Series
58-930
Series
58-930R
Series
58-924
to
58-925
Series
58-924R
to
58-925R
Series
Oil Separator - Accessible Coalescent
Part #
Maximum
Working
Pressure
Oil
Connector
Size
Diameter
Dimensions
Oil Change
Amount
Weight
"A"
"B"
"C"
58-924
450 PSIG 1/4" SAE 4"
1 1/8" ODS 15 5/16" 18 5/8" 16oz 475ml 16lbs.
58-925
450 PSIG 1/4" SAE 4"
1 3/8" ODS 15 5/16" 18 5/8" 16oz 475ml 16lbs.
58-924R
450 PSIG 1/4" SAE 4"
1 1/8" ODS 25 1/16" 28 3/8" 109oz 3.22lit 21lbs.
58-925R
450 PSIG 1/4" SAE 4"
1 3/8" ODS 25 1/16" 28 3/8" 109oz 3.22lit 21lbs.
Oil Separators
