Refrigeration
Copper Solder Tees
• Extra depth slip fit solder cups.
• Bend, cut, flare, swage or pinch.
• Simple installation anywhere along line.
Part #
Slip Fit
OAL
Over-all Length
Length
"A"
Package
02-C31134
1/4" OD
2 1/8"
1"
3/pk
02-C31135
5/16" OD
2 1/8"
1"
3/pk
02-C31136
3/8" OD
2 1/8"
1"
3/pk
02-C31138
1/2" OD
2 1/8"
1"
3/pk
02-C31140
5/8" OD
2 1/2"
1"
1/pk
02-C31142
3/4" OD
3"
1 1/4"
1/pk
02-C31144
7/8" OD
3 1/2"
1 1/2"
1/pk
02-C31148
1 1/8" OD
3 13/16""
1 5/8"
1/pk
02-C31154
3/16" OD
4"
1 15/16"
2/pk
02-C31155
1/4" OD
4"
1 15/16"
2/pk
02-C31156
5/16" OD
4"
1 15/16"
2/pk
Note: Use flux free phos-copper solder.
1/4" Access
Copper Solder Tees - Swaged
• Solder cup ends.
• Simple installation anywhere along line.
Part #
Slip Fit
OAL
Over-all Length
Package
02-C31334
1/4" OD
2 1/8"
3/pk
02-C31335
5/16" OD
2 1/8"
3/pk
02-C31336
3/8" OD
2 1/8"
3/pk
02-C31338
1/2" OD
2 1/8"
3/pk
02-C31340
5/8" OD
2 1/2"
1/pk
02-C31342
3/4" OD
3"
1/pk
02-C31344
7/8" OD
3 1/2"
1/pk
02-C31348
1 1/8" OD
3 13/16"
1/pk
Note: Use flux free phos-copper solder.
Copper Access Union
• Retrofit any existing ball.
• Install valve in any position.
Part #
Connecting
Line Size
"A"
(OAL)
"B"
(min.)
Package
02-C31199
1/4" OD 2 3/4"
5/16"
2/pk
02-C31200
3/8" OD 2 3/4"
5/16"
2/pk
02-C31201
1/2" OD
3"
3/8"
2/pk
02-C31202
5/8" OD 3 1/4"
1/2"
2/pk
02-C31204
7/8" OD 3 3/4"
3/4"
2/pk
Note: Use flux free phos-copper solder.
Copper 45° Elbow
Part #
Connecting
Line Size
Package
02-C31160
5/8"
1/pk
02-C31162
3/4"
1/pk
02-C31164
7/8"
1/pk
02-C31168
1 1/8"
1/pk
Note - All access valves are available in bulk packaging of 100 pieces. by adding suffix "-B" to part number.
Access Fittings
Copper Solder Tee
Illustrated
Copper Solder Tee
Illustrated
Copper Access Union
Illustrated
Copper Elbow
Illustrated
