60
Refrigeration
Flare Connections
Flare Connection
Part #
Description
Package
02-C31614
*
1/4" female SAE flare union
w/copper gasket.
5/pk
02-C31734
*
1/4" female SAE swivel nut
w/depressor.
5/pk
Torque flare nuts 8 to 10'/lbs
*Core pre-torqued at 2.9 to 2.95 "/lbs
Brass Bodies - Straight
Part #
Description
Package
02-C31722
1/8" OD
5/pk
02-C31723
3/16" OD
5/pk
02-C31724
1/4" OD
5/pk
02-C31725
5/16" OD
5/pk
02-C31726
3/8" OD
5/pk
02-C31728
1/2" OD
3/pk
Brass Bodies - Multi-Step
Part #
Description
Package
02-C31720
3/16" x 1/4" or 3/8" steps
5/pk
02-C31729
3/16", 1/4", 5/16" or 1/2" steps
5/pk
02-C31736
1/8" x 3/16", 1/4" or 5/16 steps
3/pk
Flared Tube Connection
Part #
Description
Package
02-C31424
1/4" SAE union w/flare nut.
3/pk
02-C31444
1/4" SAE tee w/nuts.
3/pk
Flare Tube Connections
MPT Connections
Part #
Description
Package
02-C31482
* 1/8" MPT half union.
5/pk
02-C31484
* 1/4" MPT half union.
5/pk
02-C31492
1/8" MPT elbow.
3/pk
02-C31494
1/4" MPT elbow.
3/pk
*Core pre-torqued at 2.9 to 2.95 "/lbs
MPT Connections
Bulkhead Mounting
Part #
Description
Package
02-C31434
* Access x 1/4" SAE w/nut.
1/pk
02-C31727
Access x 3/16" and 1/4".
1/pk
*Core pre-torqued at 2.9 to 2.95 "/lbs
Note - All access valves are available in bulk packaging of 100 pieces. by adding suffix "-B" to part number.
Bulkhead Connections
Brass Bodies
02-C31614
Flare Fitting Adapter
Illustrated
02-C31734
Illustrated
02-C31424
Illustrated
02-C31444
Illustrated
02-C31482
02-C31484
Illustrated
02-C31492
02-C31494
Illustrated
02-C31434
Illustrated
02-C31727
Illustrated
02-C31722
02-C31728
Illustrated
02-C31729
Illustrated
02-C31720
Illustrated
02-C31736
Illustrated
Access Fittings
